Home Cables Network installation cables Cat. 7/8 installation cable Equip Instal.Kab Cat7 S/FTP 4P23 100.00m orange LSZH
Equip Instal.Kab Cat7 S/FTP 4P23 100.00m orange LSZH

EQUIP

Equip Instal.Kab Cat7 S/FTP 4P23 100.00m orange LSZH

Product Code: 187321
Barcode 4015867207819

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
awg wire size: 23
cable length: 100 m
cable shielding: S/FTP (S-STP)
cable standard: Cat7
certification: CPR, CE
compliance certificates: RoHS
conductor material: Copper
connector 1: No
connector 1 gender: No
connector 2: No
connector 2 gender: No
depth: 100000 mm
frequency: 1000 MHz
harmonized system (hs) code: 84733080
height: 7.7 mm
jacket material: Low smoke zero halogen (LSZH)
outer diameter: 7.5 mm
package depth: 130 mm
package height: 270 mm
package weight: 11.2 kg
package width: 270 mm
plug and play: Yes
product colour: Orange
quantity per pack: 1 pc(s)
weight: 11 kg
width: 7.7 mm
Description
The equip® Installation Cable is made of preeminent materials and thoroughly examined to meet or surpass industrial standards. The solid installation cable is aimed to offer sturdy wide-ranged cable deployments, including 1000BASE-T Gigabit Ethernet and 100BASE-TX Fast Ethernet.
