Roline S/FTP Cable Cat.8, Solid Wire, LSOH, 100 m

ROLINE

Roline S/FTP Cable Cat.8, Solid Wire, LSOH, 100 m

Product Code: 21.15.0005
Barcode 7630049691094

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
cable lsoh: yes
colour: yellow
colour (cable): yellow
conductor cross section (awg): AWG 22
conductor type: Solid wire
contents: 100 m
current catalog edition: C25-01.39
current catalog page: 1.39
depth of packaging (single piece): 370 mm
external cable diameter: 8.4mm
fire protection class: Eca
gross weight: 7.5
height of packaging (single piece): 200 mm
impedance: 100 Ohm
length: 100 m
length: 100 m
manufacturer: ROLINE
material (external cable mantle): PVC, LSOH
package weight (single piece): 7.5 kg
product group: Twisted Pair Cable
product type: Installation cable
quantity of wires: 8
shield type: SFTP
transfer quality: Cat8.1 / Class I
weight: 7363.3 g
width of packaging (single piece): 320 mm
Description

Category 8, the standard for next-generation twisted-pair cabling, enables up to four times faster data transfer on the same cabling type and supports 25GBASE-T and 40GBASE-T short distance applications. Our Cat. 8 cables are not only halogen-free and flame-retardant (LSOH), but also GHMT certified for quality and performance.

  • 100 meter / box
  • Impedance: 100 Ohm
  • Construction:
- 8 lines, solid copper wire, AWG22
- pairs shielded with aluminium foil
- complete shielding in tinned copper braid
  • Colour: yellow

For a Cat.8 channel link S/FTP Cabling we recommend to use the following components:
21.15.0005 ROLINE S/FTP Cable, Cat.8, Solid Wire, AWG22
26.11.0381 ROLINE Cat.8 RJ45 Keystone, Jack, toolless
21.17.3086 ROLINE Cat.8 Shielded Field Connector RJ45 plug
21.15.1851 to 21.15.1851 ROLINE S/FTP Patch Cable Solid Cat.8, Yellow (1m to 3m)
21.15.1861 to 21.15.1863 ROLINE S/FTP Patch Cable Stranded Cat.8, Yellow (1m to 3m)

For a structured cabling system we recommend to use the following components: 21.15.0005 ROLINE S/FTP Cable Cat.8, Solid Wire, LSOH, 24 m; 21.15.1853 ROLINE S/FTP Patch Cord Cat.8, solid, LSOH, yellow, 3 m; 21.15.1863 ROLINE S/FTP Patch Cord Cat.8, stranded, LSOH, yellow, 3 m; 26.11.0381 ROLINE C8 Shield RJ45 Keystone, toolless. The accredited German laboratory GHMT has tested and certified this product combination, in a 2 Connector Channel (30m), Copper, Class I up to 2 GHz; certificate no. c7794a-23.
