Lindy 50m Fibre Optic Hybrid HDMI 8K60 Kabel

LINDY

Lindy 50m Fibre Optic Hybrid HDMI 8K60 Kabel

Product Code: 38515
Barcode 4002888385152

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
awg wire size: 23
cable diameter: 4.4 mm
cable length: 50 m
cable material: Fiber optic
cable type: Round cable
certification: CE, UKCA, FCC, RoHS, REACH & California Proposition 65
connector 1: HDMI Type A (Standard)
connector 1 dimensions (wxdxh): 20.2 x 50.5 x 11 mm
connector 1 form factor: Straight
connector 1 gender: Male
connector 2: HDMI Type A (Standard)
connector 2 dimensions (wxdxh): 20.2 x 50.5 x 11 mm
connector 2 form factor: Straight
connector 2 gender: Male
data transfer rate: 48 Gbit/s
hdmi version: 2.1
maximum refresh rate: 120 Hz
operating temperature (t-t): -10 - 60 °C
product colour: Black
storage temperature (t-t): -20 - 70 °C
supported graphics resolutions: 3840 x 2160, 7680 x 4320
un number: 5
Description

Connectors

  • Connector A: HDMI Type A (Male)
  • Connector B: HDMI Type A (Male)
  • Housing Material: PVC
  • Connector Plating: Gold Plated
  • Pin Construction: Gold Plated
  • Pin Plating: Gold Plated
  • Dimensions (approx.) WxDxH: HDMI Connector: 20.2x50.5x11mm (0.8x1.99x0.43in)



Cable Construction

  • Length: 50m (164.04ft)
  • Standard: HDMI 2.1
  • Colour: Black
  • Type: Round
  • Jacket Diameter: 4.4mm (0.17in)
  • Jacket Material: PVC
  • Conductor Material: Fiber and Copper
  • Conductor Gauge: 23AWG
  • Shielding: -



Specifications

  • Supported Bandwidth: 48Gbps
  • Maximum Resolution: 7680x4320@60Hz 4:2:0 10bit, 3840x2160@120Hz 4:4:4 10bit
  • Nominal Attenuation: ≤10dB/km@850nm, ≤8dB/km@1300nm
  • Minimum Bend Radius: 50mm (1.97in)
  • Operating Temperature: -10°C - 60°C (14°F - 140°F)
  • Storage Temperature: -20°C - 70°C (-4°F - 158°F)



Miscellaneous

  • Packaging Type: Carton Box
  • Warranty (Years): 2
  • Certificated: CE, UKCA, FCC, RoHS, REACH & California Proposition 65



Purchasing Information

  • No.: 38515
  • EAN: 4002888385152



This product is also available in other lengths:

  • 38510 - 10m (32.81)
  • 38511 - 15m (49.21ft)
  • 38512 - 20m (65.62ft)
  • 38513 - 30m (98.42ft)
  • 38514 - 40m (131.23ft)
