Home Cables Optical cables 9/125 62.5/125 50/124 MTP Lindy 10m Fibre Optic Hybrid DisplayPort 2.0 UHBR10 Kabel
Lindy 10m Fibre Optic Hybrid DisplayPort 2.0 UHBR10 Kabel

LINDY

Lindy 10m Fibre Optic Hybrid DisplayPort 2.0 UHBR10 Kabel

Product Code: 38520
Barcode 4002888385206

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
awg wire size: 24
cable diameter: 4 mm
cable length: 10 m
cable material: Fibre optic/Copper
cable type: Round cable
certification: California Proposition 65
compliance certificates: CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA
connector 1: DisplayPort
connector 1 dimensions (wxdxh): 19.8 x 47.8 x 12 mm
connector 1 form factor: Straight
connector 1 gender: Male
connector 2: DisplayPort
connector 2 form factor: Straight
connector 2 gender: Male
connector contacts plating: Gold
connector housing material: PVC
data transfer rate: 40 Gbit/s
displayport version: 2.0
jacket material: Polyvinyl chloride (PVC)
maximum refresh rate: 144 Hz
maximum resolution: 7680 x 4320 pixels
operating temperature (t-t): -10 - 60 °C
package type: Box
product colour: Black
storage temperature (t-t): -20 - 70 °C
sustainability compliance: Yes
warranty period: 2 year(s)
Description

Connectors

  • Connector A: DisplayPort (Male)
  • Connector B: DisplayPort (Male)
  • Housing Material: PVC
  • Connector Plating: Gold Plated
  • Pin Construction: Gold Plated
  • Pin Plating: Gold Plated
  • Dimensions (approx.) WxDxH: DP Connector: 19.8x47.8x12mm (0.78x1.88x0.47in)



Cable Construction

  • Length: 10m (32.81ft)
  • Standard: DisplayPort 2.0
  • Colour: Black
  • Type: Round
  • Jacket Diameter: 4.0mm (0.16in)
  • Jacket Material: PVC
  • Conductor Material: Fiber and Copper
  • Conductor Gauge: 24AWG
  • Shielding: -



Specifications

  • Supported Bandwidth: 40Gbps
  • Maximum Resolution: 7680x4320@60Hz 4:2:0 10bit, 3840x2160@144Hz 4:4:4 10bit
  • Nominal Attenuation: ≤10dB/km@850nm, ≤8dB/km@1300nm
  • Minimum Bend Radius: 50mm (1.97in)
  • Operating Temperature: -10°C - 60°C (14°F - 140°F)
  • Storage Temperature: -20°C - 70°C (-4°F - 158°F)



Miscellaneous

  • Packaging Type: Carton Box
  • Warranty (Years): 2
  • Certificated: CE, UKCA, FCC, RoHS, REACH & California Proposition 65



Purchasing Information

  • No.: 38520
  • EAN: 4002888385206



This product is also available in other lengths:

  • 38521 - 15m (49.21ft)
  • 38522 - 20m (65.62ft)
  • 38523 - 30m (98.42ft)
  • 38524 - 40m (131.23ft)
  • 38525 - 50m (164.04ft)
