LINDY

Lindy Adapter USB 3.2 Typ C

Product Code: 41893
Barcode 4002888418935

To purchase this product you must be registered in our system.



Specification
compliance certificates: REACH, RoHS
connector 1: USB 3.2 Type C
connector 1 form factor: Straight
connector 1 gender: Male
connector 2: USB 3.2 Type C
connector 2 form factor: Straight
connector 2 gender: Female
connector contacts plating: Nickel/Gold
data transfer rate: 20 Gbit/s
depth: 13 mm
height: 7.5 mm
housing material: Polyvinyl chloride (PVC)
operating temperature (t-t): -10 - 80 °C
package type: Polybag
product colour: Black
storage temperature (t-t): -20 - 85 °C
width: 26.5 mm

Description

Connectors

  • Connector A: USB 3.2 Type C Male
  • Connector B: USB 3.2 Type C Female
  • Housing Material: PVC
  • Connector Plating: Nickel
  • Pin Construction: Copper
  • Pin Plating: Gold
  • Dimensions (approx.) WxDxH: 26.5x13x7.5mm (1.04x0.51x0.3in)



Specifications

  • Standard: USB 3.2 Gen 2x2
  • Supported Bandwidth: 20Gbps
  • Colour: Black
  • Shielding: Copper foil
  • Operating Temperature: -10°C - 80°C (14°F - 176°F)
  • Storage Temperature: -20°C - 85°C (-4°F - 185°F)



Miscellaneous

  • Packaging Type: Polybag
  • Warranty (Years): 10
  • Certificated: RoHs, REACH, California Proposition 65



Purchasing information

  • No.: 41893
  • EAN: 4002888418935
