Lindy USB 2.0 Smart Card Reader

LINDY

Lindy USB 2.0 Smart Card Reader

Product Code: 43407
Barcode 4002888434072

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
ce doc: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/a8/17/8d/66/668d17a86b97614f716b2cc9/CE_43407.pdf
country of origin: CN
depth: 0.000
height: 0.000
packaging height: 2.8
packaging lenght: 9.8
packaging width: 12.8
warranty: 2.0
width: 0.000
Description

Specifications

  • USB Standard: USB 2.0
  • Supported Bandwidth: 480Mbps
  • Chipset: Realtek 5169
  • Compatibility: USB Type A equipped computers
  • Power Delivery: -
  • Special Features:
    • Compliant with EMV 4.1 specification
    • Supports PC smart card industry standard PC/SC 1.0, PC/SC 2.0
    • Supports 1.8V, 3V/5V cards
    • Supports asynchronous cards: protocols T0, T1
    • Supports synchronous cards: 2-wire, 3-wire, I2C Memory Cards: SLE4418/28, SLE4432/42, AT88sc1608/153, AT24c128/256, ST M14C16/M14C04

Connectors

  • Inputs: 1 x USB Type A (Male)
  • Outputs: 1x Smart Card slot (PC/SC 1.0/2.0)
  • Power: -

Physical Properties

  • Dimensions WxDxH: 69x62x16mm (2.72x2.44x0.63in)
  • (Fixed) Cable Length: 1.2m (3.94ft)
  • Housing Material: Plastic
  • Net Weight: 0.048kg (0.1lb)
  • Operating Temperature: 0°C - 50°C (32°F - 122°F)
  • Storage Temperature: 0°C - 60°C (32°F - 140°F)
  • Humidity:  10 - 85% RH (non-condensing)
  • Power Requirements: Bus-powered
  • Colour: Black

Miscellaneous

  • Packaging Type: Carton Box
  • Packaging Dimensions: 128x98x28mm (4.84x3.86x1.1in)
  • Gross Weight: 0.1kg (0.22lb)
  • Warranty (Years): 2
  • Product Compliance: CE, FCC, RoHS, REACH

Package Contents

  • USB 2.0 Smart Card Reader

Purchasing Information

  • No.: 43407
  • EAN: 4002888434072
