Home Computer Components Docking Station Lindy DST-Mini Duo, USB C Laptop Mini Dock 2x 4K HDMI
Lindy DST-Mini Duo, USB C Laptop Mini Dock 2x 4K HDMI

LINDY

Lindy DST-Mini Duo, USB C Laptop Mini Dock 2x 4K HDMI

Product Code: 43373
Barcode 4002888433730

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
ce doc: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/f1/e0/f4/63/63f4e0f131aaaecc77652497/CE_DoC_DE_43373.pdf
compliance certificates: CE, Federal Communications Commission (FCC), REACH, RoHS
connectivity technology: Wired
copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
country of origin: CN
data transfer rate: 10 Gbit/s
depth: 49 mm
ethernet lan: Yes
ethernet lan (rj-45) ports: 1
ethernet lan data rates: 10,100,1000 Mbit/s
hd type: 8K Ultra HD
hdcp: Yes
hdcp version: 2.3
hdmi ports quantity: 2
hdmi version: 2.1
height: 21.7 mm
host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C
housing material: Aluminium, Plastic
linux operating systems supported: Yes
mac operating systems supported: Yes
manual: Yes
maximum digital resolution: 7680 x 4320 pixels
microphone in: No
mobile operating systems supported: Android
operating relative humidity (h-h): 10 - 85%
operating temperature (t-t): 0 - 40 °C
other operating systems supported: ChromeOS
package depth: 80 mm
package height: 25 mm
package weight: 200 g
package width: 185 mm
packaging height: 2.5
packaging lenght: 18.5
packaging width: 8.0
power cable length: 0.22 m
power connector: USB Type-C
power source type: USB
product colour: Grey
quantity per pack: 1 pc(s)
storage temperature (t-t): -10 - 60 °C
sustainability compliance: Yes
tech data sheets: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/03/ae/57/63/6357ae0328c20569eb0dadf8/43373_TDS_v1.pdf
usb 3.2 gen 2 (3.1 gen 2) type-a ports quantity: 5
usb 3.2 gen 2 (3.1 gen 2) type-c ports quantity: 1
usb power delivery (usb pd): Yes
usb power delivery revision: 3.0
usb power delivery up to: 100 W
wake-on-lan ready: Yes
warranty: 2.0
weight: 160 g
width: 165 mm
windows operating systems supported: Yes
Description

Specifications

  • Interface: USB Type C to 5x USB Type A / 2x USB Type C / 1x RJ45 / 2x HDMI
  • Interface Standard: USB 3.2 / 3.1 Gen 2 & Gen 1, HDMI 2.1, Gigabit LAN
  • Supported Bandwidth: 10Gbps, 10/100/100Mbps
  • Maximum Input Resolution: 8K 7680x4320 30Hz
  • Maximum Output Resolution:
    • Single display: 7680x4320 30Hz, 3840x2160 120Hz
    • Dual displays: 3840x2160 60Hz & 3840x2160 30Hz
  • Chipset: RTS5459, RTS5420, RM1211, VMM6210, PS8402AAX88179A
  • Compatibility: USB Type C or Thunderbolt 3/4 equipped computers. Windows, macOS, Linux, Android, ChromeOS.
  • Power Delivery: PD 3.0 up to 100W (20V 5A)
  • HDCP Support: HDCP 2.3
  • Supported Audio: 7.1 8 channels, sampling rate 192kHz/24bit, LPCM, DTS, AC3, HBR
  • Separate Audio Ports: -
  • Special Features: DisplayPort Alternate Mode, MST for Windows, Supports simultaneous card reading (microSD), Wake on LAN (WOL) support, Supports MAC Address pass through (this feature is dependent upon the compatibility of the hardware used in each set up)



Connectors

  • Inputs: 1 x USB Type C (Male)
  • Outputs: 2x HDMI (Female), 1x RJ45 (Female), 5x USB Type A (Female), 1x USB Type C (Female)
  • Power: 1 x USB Type C (Female) PD port



Physical Properties

  • Dimensions WxDxH: 165x49x21.7mm (6.5x1.93x0.85in)
  • (Fixed) cable length: 220m (8.66ft)
  • Housing Material: Aluminium, plastic
  • Net Weight: 0.16kg (0.35lb)
  • Operating Temperature: 0°C - 40°C (32°F - 104°F)
  • Storage Temperature: -10 °C - 60°C (14°F - 140°F)
  • Humidity: 10 - 85% RH (non-condensing)
  • Power Requirements: 15W
  • Colour: Dark Grey



Miscellaneous

  • Packaging Type: Carton Box
  • Packaging Dimensions: 185x80x25mm (7.28x3.15x0.98in)
  • Gross Weight: 0.2kg (0.44lb)
  • Warranty (Years): 2
  • Certificated: CE, UKCA, FCC, REACH & RoHS, California Proposition 65



Package Contents

  • USB-C Laptop Mini Docking Station
  • Lindy Manual



Purchasing information

  • No.: 43373
  • EAN: 4002888433730
