Lindy 8 Port HDMI 18G Splitter

Product Code: 38237

Barcode 4002888382373

To purchase this product you must be registered in our system.

Specification

Description

Related products

Specification

ac adapter included: Yes

ac input voltage: 12 V

certification: CE, FCC, REACH, California Proposition 65

compliance certificates: RoHS

country of origin: CN

dc-in jack: Yes

depth: 102 mm

harmonized system (hs) code: 85176990

hd type: 4K Ultra HD

hdcp: Yes

height: 16 mm

housing material: Metal

led indicators: Yes

manual: Yes

maximum resolution: 3840 x 2160 pixels

number of displays supported: 8

operating relative humidity (h-h): 20 - 90%

operating temperature (t-t): 0 - 40 °C

package depth: 183 mm

package height: 68 mm

package type: Box

package weight: 913 g

package width: 277 mm

packaging height: 9.5

packaging lenght: 32.0

packaging width: 30.05

product colour: Black

storage temperature (t-t): -20 - 60 °C

video out: 8x HDMI

video port type: HDMI

video ports quantity: 9

warranty: 2.0

weight: 728 g

width: 243 mm

Description

Specifications

AV Interface: HDMI
Interface Standard: HDMI 2.0
Supports Bandwidth: 18Gbps
Maximum Resolution: 3840x2160@60Hz 4:4:4 8bit
HDCP Support: 2.2
Supported Audio: Audio Pass-through
Separate Audio Ports: -
CEC Support: -
Serial Interface: -
Special Features: EDID emulation

Connectors

Input: 1 x HDMI (Female)
Output: 8 x HDMI (Female)
Control: -
Power: 5.5/2.1mm DC socket

Physical Properties

Dimensions (approx.) WxDxH: 243x102x16mm (9.57x4.02x0.63in)
Housing Material: Metal
Net Weight: 0.728kg (1.6lb)
Operating Temperature: 0°C - 40°C (32°F - 104°F)
Storage Temperature: -20°C - 60°C (-4°F - 140°F)
Humidity: 20 - 90% RH (Non-condensing)
Power Requirements: 12VDC 1A
Colour: Black

Miscellaneous

Packaging Type: Carton box
Packaging Dimensions: 277x68x183mm (10.91x2.68x7.2in)
Gross Weight: 0.913kg (2.01lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS, REACH & California Proposition 65

Package Contents

HDMI Splitter
Multi-country PSU (UK, EU, US & AUS)
Lindy Manual

Purchasing Information

No.: 38237
EAN: 4002888382373
