Bachmann craftsman socket strip 4x earthing contact, 4x switch, 2 m
To purchase this product you must be registered in our system.
Specification
colour: black / gray
colour (design profile): black / gray
connection cable: HO5VV-F3G, 2m, schwarz
connector plug: Schuko
current catalog edition: 24.1
current catalog page: 10.18
depth: 74 mm
depth of packaging (single piece): 140 mm
function: 6 fach Steckdosenleiste
gross weight: 0.925
height: 45 mm
height of packaging (single piece): 60 mm
length: 2 m
length: 2 m
manufacturer: BACHMANN
material (casing): Kunststoff
max. capacitance: 3600W
max. voltage: 230V AC
mounting form: Wall / table socket
number of socket pots: 4
on/off switch: yes
output alignment: Reihe
package weight (single piece): 0.925 kg
plug type: 3P. German, CEE 7/7, Type-E/F
product group: Power Bars
product type: Power strip
protection class (ip code): IP20
quantity of outputs/angles: 6 / 90 °
regional use: Germany, Austria, Netherlands
socket type: 3P. German, CEE 7/3, Type-F
technical particularity: Jede Buchse einzeln schaltbar
weight: 905 g
width: 453 mm
width of packaging (single piece): 530 mm
Description
Robust. Practical. High quality. - HAND-CRAFTED socket strip with 90° rotated protective contact inserts and integrated reconnection terminal for power cable.Craftsman socket strip 4-fold protective contact - 16A/3680W, AC250V, IP20 - Protective contact inserts: Colour black, rotated by 90° - Socket outlet spacing: 15mm (between inserts) - 2-pole illuminated rocker switch 16 A - Each protective contact socket can be switched individually - Connection: - Screwed and reconnectable - Integrated reconnection terminal for power cable and additional output for separate earth conductor - Additional earth conductor connection, possible without opening the housing - Cable 2.0m H05VV-F 3G1.5mm² with angled earthing contact plug - Profile: - Profile colour silver - CSO, PVC, glow wire resistant 850°C Colour RAL 7035 - |
