19" compatible: no
analogue console: monitor connection: 1x DVI F
analogue console: mouse/keyboard connection: 2x USB Type A
audio switching: Speakers and microphones
audio switching separately: yes
cascadable: no
colour: grey
colour (design profile): silver
current catalog edition: 24.1
current catalog page: 3.10
depth: 265 mm
depth of packaging (single piece): 330 mm
dimensions (hxwxd): 45 x 73 x 265 mm
gross weight: 1.986
height: 45 mm
height of packaging (single piece): 220 mm
integrated console: no
integrated hub: yes
keyboard layout: not applicable
keyboard/mouse emulation: not applicable
mains connection: Appliance Europlug, Type-C
manufacturer: ATEN
material (casing): Metal
max. resolution (nominal): 1600x1200
monitor size of integrated console: not applicable
package weight (single piece): 1.986 kg
pc: connection on moulded cables: no
pc: monitor connection: 4x DVI F
pc: mouse/keyboard connection: 4x USB Type B
power supply output: 5,3V DC 1,1A
power supply unit required: yes
print button on device: yes
product group: KVM switches / PC shares
product type: KVM-Switch, HDMI
quantity of analogue consoles: 1
quantity of digital consoles: 1
quantity of pcs: 4
quantity of usb-hub ports: 2
scope of delivery: 1x CS1794 USB 2.0 HDMI KVMP™ Switch, 4x KVM Cable (HDMI, ...
supported pc-systems: USB
switching over hot keys: Keyboard
switching over osd: no
switching over scan run: yes
technical particularity: LED display for easy status monitoring
trackball/touchpad integrated console: not applicable
usb hub switching separately: yes
weight: 0.53 kg
width: 73 mm
width of packaging (single piece): 100 mm
