10g support: No
ac input frequency: 50 - 60 Hz
ac input voltage: 100 - 240 V
auto mdi/mdi-x: Yes
auto-negotiation: Yes
basic switching rj-45 ethernet ports quantity: 16
basic switching rj-45 ethernet ports type: Fast Ethernet (10/100)
buffer size: 160 KB
cable types supported: Cat3, Cat4, Cat5
cables included: AC
certification: CE, FCC
copper ethernet cabling technology: 10BASE-T, 100BASE-TX
country of origin: Taiwan
depth: 480 mm
flow control support: Yes
full duplex: Yes
harmonized system (hs) code: 85176990
height: 44 mm
housing material: Metal
input current: 5 A
led indicators: Activity, PoE, Power
mac address table: 4000 entries
master (outer) case gross weight: 19.8 kg
master (outer) case height: 280 mm
master (outer) case length: 560 mm
master (outer) case width: 520 mm
networking standards: IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
operating relative humidity (h-h): 10 - 90%
operating temperature (t-t): 0 - 45 °C
package depth: 535 mm
package height: 90 mm
package type: Box
package weight: 3.7 kg
package width: 250 mm
packet forwarding rate (10 mbps): 14880 pps
packet forwarding rate (100 mbps): 148000 pps
plug and play: Yes
power consumption (typical): 150 W
power over ethernet (poe): Yes
power over ethernet (poe) power per port: 30 W
power over ethernet plus (poe+) ports quantity: 16
power protection features: Over current
product colour: Grey
products per master (outer) case: 5 pc(s)
quick start guide: Yes
rubber feet: Yes
storage relative humidity (h-h): 10 - 90%
storage temperature (t-t): -40 - 75 °C
store-and-forward: Yes
switching capacity: 3.2 Gbit/s
weight: 2.85 kg
width: 200 mm
