10g support: No
ac input frequency: 50 - 60 Hz
ac input voltage: 100 - 240 V
auto mdi/mdi-x: Yes
auto-negotiation: Yes
basic switching rj-45 ethernet ports quantity: 16
basic switching rj-45 ethernet ports type: Gigabit Ethernet (10/100/1000)
built-in processor: Yes
country of origin: China
depth: 180 mm
flash memory: 4 MB
flow control support: Yes
forwarding rate: 1.488 Mpps
full duplex: Yes
gigabit ethernet (copper) ports quantity: 16
half duplex: Yes
harmonized system (hs) code: 85176990
height: 44 mm
jumbo frames: 9000
jumbo frames support: Yes
mac address auto-aging supported: Yes
mac address auto-learning supported: Yes
mac address table: 8000 entries
manual: Yes
master (outer) case gross weight: 10.4 kg
master (outer) case height: 280 mm
master (outer) case length: 355 mm
master (outer) case width: 353 mm
networking standards: IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
operating relative humidity (h-h): 10 - 90%
operating temperature (t-t): 0 - 40 °C
package depth: 340 mm
package height: 66 mm
package type: Box
package weight: 1.7 kg
package width: 258 mm
pallet gross length: 80 cm
pallet gross width: 120 cm
pallet height (air): 155.5 cm
power consumption (typical): 10.1 W
power over ethernet (poe): No
processor model: Realtek RTL8382L
product colour: Grey
products per master (outer) case: 5 pc(s)
products per pallet: 22 pc(s)
rack mount kit: Yes
rack mounting: Yes
storage relative humidity (h-h): 5 - 90%
storage temperature (t-t): -40 - 70 °C
store-and-forward: Yes
switching capacity: 32 Gbit/s
weight: 2.6 kg
width: 280 mm
