Specifications

• Interface: USB to 2x PCIe/NVMe M.2 SSD
• Interface Standard: USB 3.2 Gen 2x2, PCIe 3.0 x2
• Supported Bandwidth: 20Gbps (USB), 32Gbps - each up to 16Gbps (PCI 3.0 x2)
• Chipset: JMS586U
• Compatibility: USB Type C equipped computers
• Special Features: supports 42/60/80mm SSDs, UASP & TRIM, LED indicator for Clone process

Connectors

• Inputs: 1 x USB Type C (Female)
• Outputs: 2 x PCIe based M.2 (Female), M key and B+M key
• Power: 5.5/2.5mm DC socket

Physical Properties

• Dimensions WxDxH: 143x77x17.5mm (5.63x3.03x0.69in)
• Cable Length: 0.25m (0.82ft)
• Housing Material: Aluminium and ABS
• Net Weight: 0.174kg (0.38lb)
• Operating Temperature: 5°C - 35°C  (41°F - 95°F)
• Storage Temperature: -10°C - 90°C  (-14°F - 122°F)
• Humidity: 10 - 90% RH (non-condensing)
• Power Requirements: 12VDC 2A
• Colour: Silver

Miscellaneous

• Packaging Type: Carton Box
• Packaging Dimensions: 160x100x110mm (6.30x3.94x4.33in)
• Gross Weight: 0.47kg (1.04lb)
• Warranty (Years): 2
• Product Compliance: CE, FCC, RoHS & REACH, CP65

Package Contents

• USB 3.2 Dual M.2 NVMe SSD Enclosure
• 0.25m USB 3.2 Gen 2x2 Type C to C cable
• Multi-Country Power Supply 12VDC 2A with country adapters (EU, UK; US, AUS)
• 2x thermal conductive pad
• 2x thermal conductive plate
• 4x M.2 rubber retainer
• Lindy Manual

Purchasing Information

• No.: 43382
• EAN: 4002888433822
