METZ CONNECT

Metz Connect IP44 surface-mounted module housing, hinged cover & lock, 2 port unequipped for Keystone, grey

Produkta kods: 1309470003KI
Svītrkods: 4251394665603

Lai varētu iegādāties šo produktu, jābūt reģistrētam mūsu sistēmā.

Specifikācija
colour: grey
depth: 91.1 cm
depth of packaging (single piece): 0 mm
dimensions (hxwxd): 89,9 x 91,1 x 91,1 mm
height: 89.9 cm
height of packaging (single piece): 0 mm
manufacturer: METZ CONNECT
material (casing): ASA PC
operating temperature max.: 70 °C
operating temperature min.: -20 °C
package weight (single piece): 0 kg
product group: Network Components
product type: Surface-mounted housing
protection class (ip code): IP44
ral colour: RAL 7035 Light grey
scope of delivery: Delivery without modules and screws for surface mounting
weight: 276.53 g
width: 91.1 cm
width of packaging (single piece): 0 mm

Preces apraksts

IP44 surface-mounted module housing with hinged cover and lock, gray, 2 port unequipped for Keystone

  • With two keys and keyed alike lock (same locks and keys), housing flap can be sealed
  • Protection class IP44, protected against splashing water on all sides and the ingress of solid objects larger than 1 mm.
  • IP protection classes tested without outgoing components. The protection class may differ due to the connection of components.
  • Module cut-out: Keystone
  • Two individual modules of your choice (RJ45, fibre optic LC, fibre optic ST, KOAX) available as accessories.
  • Hinged cover closes completely, even when patch cables are plugged in
  • Hinged lid can be locked in open position
  • Housing made of UV weather-resistant and break-proof thermoplastic PC/ASA
  • With clearly visible labelling area
  • Cable feed for one or two cables can be rotated 90 degrees.
  • Colour: gray (RAL 7035)
  • Cable glands available as accessories
  • Delivery without modules and screws for surface mounting
