Intronics Oem HD15M TERMINAL BLOCK

Intronics Oem HD15M TERMINAL BLOCK

Product Code: CD-MX15M
Barcode 8716065262773
Brand: INTRONICS OEM

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
connector: 15 pin HD D-sub male
connector type: D-sub
contacts: 15
country of origin: US
suitable for: 16-30 AWG cable
termination type: Screw
Description
15 pin HD D-sub Connector Male with Screw Termination

Low profile - less than 25,4mm behind the plate.
By VGA version are only RGB en H-Sync and V-Sync connected to screwterminals.
Reduce installation time and costs.
For hoods see AB4006 and AB4007

File - Datasheet 1
