Connectors

• Connector A: USB 2.0 Type A Male
• Connector B: Lightning C89 Male
• Housing Material: PVC
• Connector Plating: Nickel
• Pin Construction: Brass
• Pin Plating: Gold
• Dimensions (approx.) WxDxH:
  • A: 40x15.6x7.8mm (1.57x0.61x0.31in)
  • Lightning: 37.5x10.6x6mm (1.48x0.42x0.24in)

Cable Construction

• Length: 2m (6.56ft)
• Standard: USB 2.0
• Power Delivery: -
• Colour: Black
• Type: Round
• Jacket Diameter: 3.6mm (0.14in)
• Jacket Material: PVC
• Conductor Material: Tinned Copper
• Conductor Gauge Power: 22AWG
• Conductor Gauge Data: 28AWG
• Shielding: Tinned Copper Braid

Specifications

• Supported Bandwidth: 480Mbps
• Minimum Bend Radius: 35mm (1.38in)
• Operating Temperature: 0°C - 40°C (32°F - 104°F)
• Storage Temperature: -10°C - 60°C (14°F - 140°F)

Miscellaneous

• Packaging Type: Carton Box
• Warranty (Years): 2
• Product Compliance: CE, UKCA, RoHS, REACH, California Proposition 65, MFi

Purchasing Information

• No. 31292
• EAN: 4002888312929

This product is also available in other lengths

• 31290 - 0.5m (1.64ft)
• 31291 - 1m (3.28ft)
• 31292 - 2m (6.56ft)
• 31293 - 3m (9.84ft)
