Digitus 8 port Fast Ethernet network PoE switch, industrial, unmanaged, 1 SFP uplink
To purchase this product you must be registered in our system.
Specification
country of origin: CN
depth: 0.220
height: 0.070
height(cm): 21.3
length(cm): 6.6
volume(cm3): 2221.16
weight(kg): 0.917857
width: 0.160
width(cm): 15.8
Description
| Industrial 8+1 Port Fast Ethernet PoE Switch Unmanaged, 8 RJ45 Ports 10/100 Mbits The DN-651133 is an 8+1 port PoE Ethernet switch (IEEE 802.3 af/at) suitable for industrial applications (IP40) that offers interference-free data transfer performance in harsh industrial environments. The use of a high-quality photoelectric integration module ensures good transmission rates for optical and electrical connections. Ensures reliable data transmission Supports full-duplex or half-duplex mode, with automatic negotiation Network connection supports automatic cross-identification Uses "Store and Forward" technology The switch supports a variety of protocols complies with industrial operating standards Operating voltage: DC 48-57V Lightning surge protection (power): 5000A(8/20us) DN-651133 is an industrial Fast Ethernet PoE switch with 8 port 10/100Mbps RJ45 +1 port 100Mbps base-FX. The industrial switch has the operating temperature of -40°C ~ 80°C, has been ruggedized and can be used in all kinds of harsh environments. The switch can be easily installed on a free DIN rail. The wide temperature range, IP40-rated housing and LED indicator make the DN-651133 an industrial-grade plug-and-play device that provides users with a reliable and convenient solution for networking their Ethernet devices. Number of ports: 8 PoE standard: IEEE802.3af (PoE) Ethernet speed: Fast Ethernet Industrial usage: true Installation type: DIN rail Managed: false Number of ports (Uplink): 1 Outdoorsuitable: false PoE (Power over Ethernet): true Protection against vanadlism: false Uplink port connection: SFP VLAN: false 8 ports 10/100 Base-Tx RJ45 with auto-negotiation and Auto-MDI/ MDI-X function 1-port 100Base-Fx interface SFP 48V to 57V DC, redundant power connection possible Operating temperature: - 40°C to 80°C IP40 aluminum housing Supports 6KV DC Ethernet ESD protection Supports 6KV DC EFT protection for the power line Vibration, shock and drop protection Performance specification: Bandwidth: 1.8Gbps, Packet buffer memory: 1.25Mbit, Packet forwarding rate: 1.4Mpps, MAC address table: 2K Flow control: utilizes backpressure technology for half-duplex, utilizes "pause frame" technology in full-duplex mode Housing: aluminum housing with protection class IP40 LED display: Power: Red, Fiber: Link 2(Green), Ethernet: Yellow Power consumption: <8 watts Network protocols: IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u;100Base-TX/FX; Industry standard: FCC CFR47 Part 15, EN55022/CISPR22, Class A, IEC61000-4-2 (ESD): ±8kV (contact), ±12kV (air), IEC61000-4-3 (RS): 10V/m (80~1000MHz), IEC61000-4-4 (EFT): power connection: ±4kV; data connection: ±2kV, IEC61000-4-5 (overvoltage) Dimensions (W x D x H): 142.5 x 107.1 x 53.5 mm Working environment: Operating temperature: -40 to max 80°C; Storage temperature: -40 to max 80°C Relative humidity: 5% to max. 95% (no condensation) PoE power budget: 200 W Package content: 8+1 port PoE Ethernet switch Manual |
