19" compatible: nein
analogue console: monitor connection: 1x DVI BU
analogue console: mouse/keyboard connection: USB
cascadable: nein
colour: black
current catalog edition: 24.1
depth: 161 mm
depth of packaging (single piece): 140 mm
dimensions (hxwxd): 44 x 437 x 161 mm
gross weight: 4.574
height: 44 mm
height of packaging (single piece): 240 mm
integrated console: nein
integrated hub: ja
keyboard/mouse emulation: ja
mains connection: Gerät-Eurostecker, Typ-C
manufacturer: ATEN
material (casing): Metall
max. resolution (nominal): DVI Dual Link: 2560 x 1600; VGA: 2048 x 1536
package weight (single piece): 4.574 kg
pc: connection on moulded cables: nein
pc: monitor connection: 8x DVI BU
pc: mouse/keyboard connection: USB
power supply output: DC 5.3V, 6.47 W
power supply unit required: ja
print button on device: ja
product group: KVM-Switches / PC-Shares
product type: KVM-Switch, DVI
quantity of analogue consoles: 1
quantity of digital consoles: 1
quantity of pcs: 8
quantity of usb-hub ports: 2
scope of delivery: 1x CS1788 8-Port-KVM-Switch mit USB für DVI-Grafik mit Ki...
supported pc-systems: USB
switching over hot keys: Tastatur
switching over osd: nein
switching over scan run: ja
technical particularity: Dual Link DVI
weight: 2.8 kg
width: 437 mm
width of packaging (single piece): 550 mm
