3d: Yes
awg wire size: 28
bend radius (min): 7.3 cm
cable diameter: 7.3 mm
cable length: 3 m
cable material: Tinned copper
cable shielding: Copper
cable type: Round cable
certification: RoHS, REACH, UL
colour sampling: 4:4:4
compliance certificates: REACH, RoHS
connector 1: DisplayPort
connector 1 dimensions (wxdxh): 19.7 x 12 x 38.9 mm
connector 1 form factor: Straight
connector 1 gender: Male
connector 2: DisplayPort
connector 2 dimensions (wxdxh): 19.7 x 12 x 38.9 mm
connector 2 form factor: Straight
connector 2 gender: Male
connector contacts plating: Gold
connector housing material: Acrylonitrile butadiene styrene (ABS)
connector material: Gold
contact material: Phosphor bronze
data transfer rate: 21.6 Gbit/s
displayport version: 1.2
harmonized system (hs) code: 84733080
jacket material: Polyvinyl chloride (PVC)
manual: Yes
maximum refresh rate: 60 Hz
maximum resolution: 4096 x 2160 pixels
nominal attenuation: 300kHz-825MHz 5dB, 825MHz-2.475GHz 5dB, 2.475GHz-4.125GHz 12dB, 4.125GHz-5.1GHz 20dB
operating temperature (t-t): -20 - 80 °C
package type: Polybag
pallet net height: 3.89 cm
product colour: Chrome, Grey
product or article information sheet available?: Yes
storage temperature (t-t): -25 - 85 °C
supported video modes: 2160p
