Specification

• AV Interface: HDMI
• Interface Standard: HDMI 1.4
• Supported Bandwidth: 10.2Gbps
• Maximum Input Resolution: 3840x2160@30Hz 4:4:4 8bit
• Maximum Output Resolution: 1920x1080@60Hz 4:4:4 8bit
• HDCP Support: 1.4
• Supported Audio: Audio Pass Through on HDMI Output 1
• Separate Audio Ports: 3.5mm Stereo
• Special Features: Daisy Chain of 2 devices video for wall layouts up to 3x4 or 4x4

Connectors

• Input: 1 x HDMI Type A (Female)
• Output: 9 x HDMI Type A (Female)
• Power: 5.5/2.1mm DC socket

Physical Properties

• Dimensions (approx.) WxDxH: 305x185x35mm (12.01x7.28x1.38in)
• Housing Material: Metal
• Net Weight: 1.747kg (3.85lb)
• Operating Temperature: -10°C - 45°C (14°F - 113°F)
• Storage Temperature: -10°C - 80°C (14°F - 176°F)
• Humidity: 10-85% RH (non-condensing)
• Power Requirements: 12VDC 3A
• Colour: Black

Miscellaneous

• Packaging Type: Carton Box
• Packaging Dimensions: 353x295x70mm (13.9x11.61x2.76in)
• Gross Weight: 2.42kg (5.34lb)
• Warranty (Years): 2
• Product Compliance: CE, UKCA, FCC, REACH, California 65 & RoHS

Package Contents

• 9 Port HDMI Video Wall Scaler
• Multi-Country Power Supply  (US, UK, EU & AUS)
• Remote Control
• Lindy Manual

Purchasing Information

• No.: 38261
• EAN: 4002888382618
