2.4 ghz: No
5 ghz: Yes
6 ghz: No
antenna direction type: Omni-directional
antenna features: Integrated antenna
antenna gain level (max): 13 dBi
antenna type: Internal
antennas quantity: 1
auto wireless distribution system (wds): Yes
automatic channel scanning: Yes
automatic channel selection: Yes
bandwidth: 5 GHz
built-in processor: Yes
cables included: AC
cabling technology: 10/100Base-T(X)
certification: - FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
- RoHS
compatible operating systems: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
dc voltage range: 16 - 27 V
dc-in jack: Yes
depth: 79 mm
ethernet lan (rj-45) ports: 1
ethernet lan data rates: 10,100 Mbit/s
firmware upgradeable: Yes
flash memory: 8 MB
frequency band: 5.15 - 5.85 GHz
height: 60.3 mm
housing material: Plastic
igmp snooping: Yes
internal memory: 64 MB
international protection (ip) code: IP5X
ip address filtering: Yes
led indicators: Yes
mac address filtering: Yes
management platform: Pharos Control
management protocols: TDMA
maximum data transfer rate: 300 Mbit/s
maximum data transfer rate (5 ghz): 300 Mbit/s
maximum outdoor range: 15000 m
mounting kit: Yes
networking standards: IEEE 802.11a, IEEE 802.11n
operating relative humidity (h-h): 10 - 90%
operating temperature (t-t): -30 - 70 °C
package depth: 270 mm
package height: 106 mm
package weight: 720 g
package width: 132 mm
placement: Pole, Wall
poe adapter included: Yes
power consumption (typical): 13 W
power over ethernet (poe): Yes
processor architecture: MIPS 74Kc
processor frequency: 560 MHz
processor model: Qualcomm Atheros
product colour: White
quantity per pack: 1 pc(s)
receiver sensitivity: 802.11a:
54M: -75dBm, 48M: -76dBm, 36M: -83dBm, 6-24M: -95dBm
802.11n:
MCS15: -73dBm, MCS14: -74dBm, MCS13: -76dBm,
MCS12: -80dBm, MCS11: -83dBm, MCS10: -88dBm,
MCS9: -90dBm, MCS8: -93dBm, MCS7: -73dBm,
MCS6: -74dBm, MCS5: -76dBm, MCS4: -80dBm,
MCS3: -83dBm, MCS2: -88dBm, MCS1: -90dBm, MCS0: -93dBm
reset button: Yes
security algorithms: AES, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
service set identifier (ssid) features: SSID broadcast, SSID broadcast on/off
storage relative humidity (h-h): 5 - 95%
storage temperature (t-t): -40 - 70 °C
syslog: Yes
throughput data rate: 300 Mbit/s
universal plug and play (upnp): Yes
virtual lan features: Tagged VLAN
vlan support: Yes
wan connection: Ethernet (RJ-45)
web-based management: Yes
width: 224.4 mm
wireless isolation: Yes
