Sākums UPS / Barošanas elementi UPS lineinteractive APC USV BX500MI BACKUPS 500VA AVR IEC-Ausgänge

APC USV BX500MI BACKUPS 500VA AVR IEC-Ausgänge

Produkta kods: BX500MI

Svītrkods: 0731304435648

Ražotājs: APC

Lai varētu iegādāties šo produktu, jābūt reģistrētam mūsu sistēmā.

Specifikācija

Preces apraksts

Līdzīgas preces

Specifikācija

depth: 0.370

height: 0.185

width: 0.220

Preces apraksts

Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.

Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance

Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Surge only outlets
Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.

Battery and surge protected outlets
Back up and protect your hardware and data during power outages, surges and spikes .

Battery-protected and surge-only outlets
Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment

Audible alarms
Provides notification of changing utility power and UPS power conditions

LED status display
Quickly understand unit and power status with visual indicators.

UPS topology	Line-Interactive
Output power capacity	0.5 kVA
Output power	300 W
Waveform	Sine
Input operation voltage (min)	140 V
Input operation voltage (max)	300 V
Input frequency	50/60 Hz
Output frequency	50/60 Hz
Automatic Voltage Regulation (AVR)	Jā
Surge energy rating	273 J
Efficiency	96.1%
Input power factor	0.63
Noise level	40 dB
Surge protection	Jā
Audible alarm(s)	Jā
Audible alarm modes	Alarm when on battery, Low battery alarm
AC outlet types	C13 coupler
Power plug	C14 coupler
AC outlets quantity	3 AC outlet(s)
Number of output IEC jumpers	1
Ethernet LAN (RJ-45) ports	2
Cabling technology	10/100/1000Base-T(X)
Battery technology	Sealed Lead Acid (VRLA)
Battery voltage	12 V
Battery life (max)	5 year(s)
Battery recharge time	8 h
Automatic battery test	Jā
Form factor	Tower
Product colour	Black
Cable length	1.5 m
LED indicators	Battery replacement
International Protection (IP) code	IP20
Certification	CE, EAC, EN/IEC 62040-1
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 40 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 3000 m
Sustainability certificates	RoHS
Width	98 mm
Depth	310 mm
Height	138 mm
Weight	4.2 kg
Package width	142 mm
Package depth	346 mm
Package height	222 mm
Package weight	4.5 kg
Harmonized System (HS) code	85078000
