Home Adapters / Converters Displayport Lindy Mini-DisplayPort an HDMI 2.0 DVI-D & VGA Konverte
Lindy Mini-DisplayPort an HDMI 2.0 DVI-D & VGA Konverte

LINDY

Lindy Mini-DisplayPort an HDMI 2.0 DVI-D & VGA Konverte

Product Code: 38297
Barcode 4002888382977

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
cable length: 0.15 m
connector 1: Mini DisplayPort
connector 1 form factor: Straight
connector 1 gender: Male
connector 2: DVI-D + VGA (D-Sub) + HDMI
connector 2 gender: Female
depth: 60 mm
displayport version: 1.2
harmonized system (hs) code: 84733080
hdcp: Yes
hdmi version: 2.0
height: 16.5 mm
maximum resolution: 3840 x 2160 pixels
operating relative humidity (h-h): 10 - 85%
operating temperature (t-t): 0 - 70 °C
plug and play: Yes
product colour: White
storage relative humidity (h-h): 0 - 90%
storage temperature (t-t): -20 - 50 °C
weight: 6 g
width: 60 mm
Description

Specifications

  • AV Interface: Mini DisplayPort to HDMI, VGA, DVI
  • Interface Standard: DisplayPort 1.2, HDMI 2.0, DVI-D, VGA
  • Supported Bandwidth: 21.6Gbps
  • Maximum Input Resolution: 3840x2160@60Hz 4:4:4 8bit
  • Maximum  Output Resolution:
    • VGA: 1920x1200@60Hz
    • HDMI: 3840x2160@60Hz 4:4:4 8bit
    • DVI: 1920x1200@60Hz
  • Chipset:
    • HDMI & DVI: PS176
    • VGA: ANX9833
    • MiniDP: NX3DV642
  • HDCP Support: HDCP 2.2
  • Supported Audio: Pass-through
  • Separate Audio Ports: -
  • Special Features: -



Connectors

  • Input: Mini DisplayPort Male
  • Output:
    • HDMI Type A Female
    • VGA Female
    • DVI-D Female

    •

Physical properties

  • Dimensions (approx.) WxDxH: 60x16.5x60mm (2.36x0.65x2.36in)
  • Cable Length: 150mm (5.91in)
  • Housing Material: Plastic
  • Jacket Material: PVC
  • Jacket Diameter: 0.5mm (0.02in)
  • Minimum Bend Radius: 45mm (1.77in)
  • Net Weight: 0.053kg (0.12lb)
  • Operating Temperature: 0°C - 70°C (32°F - 158°F)
  • Storage Temperature: 0°C - 70°C (32°F - 158°F)
  • Humidity: 10 - 85% RH (non-condensing)
  • Colour: White



Miscellaneous

  • Packaging Type: Polybag
  • Packaging Dimensions: 160x160x20mm (6.3x6.3x0.79in)
  • Gross Weight: 0.059kg (0.13lb)
  • Warranty (Years): 2
  • Certificated: CE, FCC, RoHS & REACH



Package Contents

  • Mini DisplayPort 1.2 to HDMI 2.0 18G, DVI & VGA Active Converter



Purchasing Information

  • No.: 38297
  • EAN: 4002888382977
