Home Adapters / Converters Displayport Lindy Mini DisplayPort auf DVI Konverter, aktiv
Lindy Mini DisplayPort auf DVI Konverter, aktiv

LINDY

Lindy Mini DisplayPort auf DVI Konverter, aktiv

Product Code: 41736
Barcode 4002888417365

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
cable jacket material: Polyvinyl chloride (PVC)
cable length: 0.16 m
certification: CE, FCC, RoHS & REACH, CP65
chipset: PS171
connection to pc: Yes
connector 1: Mini DisplayPort
connector 1 form factor: Straight
connector 1 gender: Male
connector 2: DVI-D
connector 2 form factor: Straight
connector 2 gender: Female
converter type: Active video converter
depth: 44.3 mm
displayport version: 1.2
hdcp: Yes
height: 14.8 mm
host interface: Mini DisplayPort
housing material: Acrylonitrile butadiene styrene (ABS)
maximum refresh rate: 60 Hz
maximum resolution: 1920 x 1200 pixels
operating temperature (t-t): 0 - 45 °C
package depth: 194 mm
package weight: 40 g
package width: 174 mm
plug and play: Yes
product colour: Black
storage temperature (t-t): -10 - 70 °C
weight: 30 g
width: 45 mm
Description

Specifications

  • AV Interface: Mini DisplayPort to DVI
  • Interface Standard: DisplayPort 1.2 / DVI
  • Supported Bandwidth: 5.4Gbps
  • Maximum Input Resolution: 1920x1200@60Hz
  • Maximum  Output Resolution: 1920x1200@60Hz
  • Chipset: PS171
  • HDCP Support: HDCP 1.3
  • Supported Audio: -
  • Separate Audio Ports: -
  • Special Features: -



Connectors

  • Input: Mini DisplayPort Male
  • Output: DVI-D Female



Physical properties

  • Dimensions (approx.) WxDxH:
    • 11x18.7x9mm (0.43x0.74x0.35in) / mDP
    • 45x44.3x14.8mm (1.77x1.74x0.58in)
  • Cable Length: 160mm (6.3in)
  • Housing Material: ABS
  • Jacket Material: PVC
  • Jacket Diameter: 5.0mm (0.20in)
  • Minimum Bend Radius: 45mm (1.77in)
  • Net Weight: 0.030kg (0.07lb)
  • Operating Temperature: 0°C - 45°C (32°F - 113°F)
  • Storage Temperature: -10°C - 70°C (14°F - 158°F)
  • Humidity: 20 - 90% RH (non-condensing)
  • Colour: Black



Miscellaneous

  • Packaging Type: Polybag
  • Packaging Dimensions: 174x194mm (6.85x7.64in)
  • Gross Weight: 0.04kg (0.09lb)
  • Warranty (Years): 2
  • Certificated: CE, FCC, RoHS & REACH, CP65



Package Contents

  • Mini DisplayPort to DVI Active Converter



Purchasing Information

  • No.: 41736
  • EAN: 4002888417365
