Home Cables Audio / Video Lindy Patchkabel Cat6A S/FTP PIMF LSOH weiß 1.50m
Lindy Patchkabel Cat6A S/FTP PIMF LSOH weiß 1.50m

LINDY

Lindy Patchkabel Cat6A S/FTP PIMF LSOH weiß 1.50m

Product Code: 47193
Barcode 4002888471930

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
awg wire size: 27
cable class: E
cable length: 1.5 m
cable shielding: S/FTP (S-STP)
cable standard: Cat6
cabling technology: 10/100/1000Base-T(X)
connector 1: RJ-45
connector 1 gender: Male
connector 2: RJ-45
connector 2 gender: Male
connector contacts plating: Gold
data transfer rate: 1000 Mbit/s
harmonized system (hs) code: 84733080
plug and play: Yes
product colour: White
quantity per pack: 1 pc(s)
Description

Connectors

  • Connector A: RJ45 Male
  • Connector B: RJ45 Male
  • Housing Material: Polycarbonate
  • Connector Plating: Nickel
  • Pin Construction: Brass
  • Pin Plating: Gold plated
  • Dimensions (approx.) WxDxH: 11.6x21.5x8.3mm (0.46x0.85x0.33in)



Cable Construction

  • Length: 1.5m (4.92ft)
  • Colour: White
  • Type: Cat.6A
  • Jacket Diameter: 6.0mm (0.24in)
  • Jacket Material: LSZH
  • Conductor Material: Copper
  • Conductor Gauge: 27AWG
  • Shielding: Aluminium Braid



Specifications

  • Supported Bandwidth: 500MHz
  • Nominal Attenuation: 49.3dB/100m @ 500MHz
  • Minimum Bend Radius: 72mm (2.84in)
  • Operating Temperature: -10°C - 60°C (14F - 140°F)
  • Storage Temperature: -20°C - 75°C (-4F - 167°F)



Miscellaneous

  • Packaging Type: Polybag
  • Warranty (Years): 10
  • Certificated: RoHS, REACH, UL
  • Purchasing Information
  • No.: 47193
  • EAN: 4002888471930



This product is also available in other lengths:

  • 47190 - 0.3m (0.98ft)
  • 47191 - 0.5m (1.64ft)
  • 47192 - 1m (3.28ft)
  • 47193 - 1.5m (4.92ft)
  • 47194 - 2m (6.56ft)
  • 47195 - 3m (9.84ft)
  • 47196 - 5m (16.44ft)
  • 47197 - 7.5m (24.61ft)
  • 47198 - 10m (32.81ft)
  • 47199 - 15m (49.21ft)
  • 47200 - 20m (65.62ft)
  • 47201 - 30m (98.43ft)
