Home Cables Displayport Lindy Mini-DisplayPort an DVI-D Kabel schwarz 1m
Lindy Mini-DisplayPort an DVI-D Kabel schwarz 1m

LINDY

Lindy Mini-DisplayPort an DVI-D Kabel schwarz 1m

Product Code: 41951
Barcode 4002888419512

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
cable length: 1 m
connector 1: Mini DisplayPort
connector 1 gender: Male
connector 2: DVI-D
connector 2 gender: Male
country of origin: CN
data transfer rate: 1.65 Gbit/s
displayport version: 1.2
harmonized system (hs) code: 84733080
maximum resolution: 1920 x 1200 pixels
packaging height: 19.4
packaging lenght: 17.4
packaging width: 2.0
product colour: Black
quantity per pack: 1 pc(s)
supported graphics resolutions: 1920 x 1200 (WUXGA)
variation of: 41950.0
warranty: 2.0
Description

Connectors

  • Connector A: Mini DisplayPort Male
  • Connector B: DVI-D Male
  • Housing Material:
    • Mini DisplayPort: ABS
    • DVI: PVC
  • Connector Plating: Nickel plated
  • Pin Construction: Copper
  • Pin Plating: Gold plated
  • Dimensions (approx.) WxDxH:
    • Mini DisplayPort: 18x11x9.3mm (0.7x0.43x0.37in)
    • DVI: 48.5x39.5x16.5mm (1.91x0.77x0.65in)

Cable Construction

  • Length: 1m (3.28ft)
  • Standard: DVI-D (Single Link), DisplayPort 1.2
  • Colour: Black
  • Type: Round
  • Jacket Diameter: 5.5mm (0.22in)
  • Jacket Material: PVC
  • Conductor Material: Tinned Copper
  • Conductor Gauge: 32AWG
  • Shielding: Aluminum Braid 75%

Specifications

  • Supported Bandwidth: 1.65Gbps
  • Maximum Resolution: 1920x1200@60Hz
  • Nominal Attenuation:
    • 300KHz-825MHz  <5dB
    • 825MHz-2.475GHz  <5dB - <12dB
  • Minimum Bend Radius: 33mm (1.3in)
  • Operating Temperature: -20°C - 40°C (-4°F - 104°F)
  • Storage Temperature: -40°C - 80°C (-40°F - 176°F)

Miscellaneous

  • Packaging Type: Polybag
  • Warranty (Years): 2
  • Product Compliance: CE, UKCA, FCC, RoHS, REACH, UL & California Proposition 65

Purchasing Information

  • No.: 41951
  • EAN: 4002888419512

This product is also available in other lengths

  • 41951 - 1m (3.28ft)
  • 41952 - 2m (6.56ft)
  • 41953 - 3m (9.84ft)
