Home Cables Network installation cables Cat.5e installation cable Roline UTP Cable Cat.5e, Stranded Wire 300 m
Roline UTP Cable Cat.5e, Stranded Wire 300 m

ROLINE

Roline UTP Cable Cat.5e, Stranded Wire 300 m

Product Code: 21.15.0520
Barcode 7611990937189

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
cable lsoh: no
colour: grey
conductor cross section (awg): AWG 24
conductor type: Stranded
contents: 300 m
current catalog edition: C25-01.15
current catalog page: 1.48
depth of packaging (single piece): 370 mm
gross weight: 12.4
height of packaging (single piece): 250 mm
impedance: 100 Ohm
length: 300 m
length: 300 m
manufacturer: ROLINE
material (external cable mantle): PVC
package weight (single piece): 12.4 kg
product group: Twisted Pair Cable
product type: Raw cable Cat.5e
quantity of wires: 8
shield type: UTP
transfer quality: Cat5e / Class D
weight: 10.33 kg
width of packaging (single piece): 380 mm
Description

  • Structured building wiring
  • Impedance: 100 Ohm
  • 3P verified
  • Colour: Grey
  • Construction 21.15.0520: 8 lines, copper, stranded wire AWG24
  • Diagram: attenuation/near end crosstalk

For a structured cabling system we recommend to use the following components:
ROLINE Cat.5e UTP Cable, Solid Wire, AWG24: 21.15.0512 (100 m), 21.15.0511 (300 m)
ROLINE Cat.5e Flush/Surface Mount Wall Jack, unshielded: 25.16.8506 (white), 25.16.8501 (ivory)/25.16.8406 (white), 25.16.8401 (ivory)
ROLINE Cat.5e 19" Patch Panel, 24 Ports, unshielded: 26.11.0349 (black), 26.11.0347 (light grey)
ROLINE Cat.5e UTP Patch Cord, grey, 5 m: 21.15.0505

Our in-house laboratory has tested this cable-plug combination, in a Channel of 100 meters, in compliance with Class D specifications.
