Lindy 5m USB 3.2 10Gbps C/C Active Extension Pro

LINDY

Lindy 5m USB 3.2 10Gbps C/C Active Extension Pro

Product Code: 43405
Barcode 4002888434058

To purchase this product you must be registered in our system.



Specification
Description
Related products
Specification
awg wire size: 24/26
cable diameter: 5 mm
cable jacket material: Polyvinyl chloride (PVC)
cable length: 5 m
cable type: Round cable
ce doc: CE_43405.pdf
compliance certificates: CE, Federal Communications Commission (FCC), REACH, RoHS, Trade Agreements Act (TAA), UKCA
conductor material: Copper
connector 1: USB C
connector 1 form factor: Straight
connector 1 gender: Male
connector 2: USB C
connector 2 form factor: Straight
connector 2 gender: Female
connector contacts plating: Nickel
country of origin: TW
maximum data transfer rate: 10 Gbit/s
package depth: 50 mm
package height: 170 mm
package type: Box
package weight: 370 g
package width: 160 mm
packaging height: 20.0
packaging lenght: 23.5
packaging width: 6.5
product colour: Black
quantity per pack: 1 pc(s)
usb version: USB 3.2 Gen 2 (3.1 Gen 2)
warranty: 2.0
weight: 230 g
Description
Connectors
  • Connector A: USB Type C Male
  • Connector B: USB Type C Female
  • Power: 2.5/0.7mm DC Connector
  • Housing Material: Plastic
  • Connector Plating: Nickel
  • Pin Construction: Brass
  • Pin Plating: Gold Flash
  • Dimensions (approx.) WxDxH:
    • USB C Male: 14x41x11.2mm (0.49x1.56x0.35in)
    • USB C Female: 22x82x16.1mm (0.86x3.23x0.63in)
Cable Construction
  • Length: 5m (16.4ft)
  • Standard: USB 3.2 / 3.1 Gen 2
  • Colour: Black
  • Type: Round
  • Jacket Diameter: 5mm +/- 0.15mm (0.22in +/- 0.01in)
  • Jacket Material: Half matt PVC low toxic
  • Conductor Material: Tinned Copper
  • Conductor Gauge: 26/26/24AWG
  • Shielding: AL Mylar and braid
Specifications
  • Supported Bandwidth: 10Gbps
  • Nominal Attenuation:
    • 0.064MHz - <0.08dB
    • 0.256MHz - <0.11dB
    • 0.512MHz - <0.13dB
    • 0.772MHz - <0.15dB
    • 1.0MHz - <0.20dB
    • 4MHz - <0.39dB
    • 8MHz - <0.57dB
    • 12MHz - <0.67dB
    • 24MHz - <0.95dB
    • 48MHz - <1.35dB
    • 96MHz - <1.90dB
    • 200MHz - <3.20dB
    • 400MHz - <5.80dB
  • Minimum Bend Radius: 60mm (2.36in)
  • Maximum Tensile Load: -
  • Operating Temperature: 0°C - 50°C (32°F - 122°F)
  • Storage Temperature: -20°C - 75°C (-4°F - 167°F)
  • Transmission Medium: Twisted Pair
  • Transmission Technology: USB 3.2 / 3.1 Gen 2

Miscellaneous
  • Packaging Type: Carton Box
  • Packaging Dimensions: 235x200x65mm (9.25x7.87x2.56in)
  • Net Weight: 0.23kg (0.51lb)
  • Gross Weight: 0.37kg (0.82lb)
  • Warranty (Years): 2
  • Certificated: CE, FCC, RoHS, REACH & California Proposition 65, TAA
Packaging Content
  • USB 3.2 Gen 2 C/C Active Extension Pro 5m
  • Power Adapter Cable Nr. 70265
  • Lindy Manual
Purchasing Information
  • No.: 43405
  • EAN: 4002888434058
