Icy Box Dockingstation IcyBox Thunderbolt 4xUSB Type-A, 2xType-C
To purchase this product you must be registered in our system.
Specification
ac input frequency: 50 - 60 Hz
ac input voltage: 100-240 V
cable lock slot: Yes
cable lock slot type: Kensington
cables included: DC, Thunderbolt
card reader integrated: Yes
combo headphone/mic port: Yes
compatible memory cards: SD
connectivity technology: Wired
country of origin: China
data transfer rate: 40 Gbit/s
dc-in jack: Yes
depth: 75 mm
ethernet lan: Yes
ethernet lan (rj-45) ports: 1
ethernet lan data rates: 10,100,1000,2500 Mbit/s
hd type: 8K Ultra HD
hdmi ports quantity: 1
headphone outputs: 1
height: 31 mm
host interface: Thunderbolt 4
housing material: Aluminium
led indicators: Yes
mac operating systems supported: Yes
manual: Yes
master (outer) case gross weight: 12.6 kg
master (outer) case height: 500 mm
master (outer) case length: 315 mm
master (outer) case width: 305 mm
maximum refresh rate: 60 Hz
microphone in: No
number of displays supported: 2
on/off switch: Yes
output current: 6.75 A
output voltage: 5 - 20 V
package depth: 92 mm
package height: 158 mm
package weight: 1.33 kg
package width: 290 mm
plug and play: Yes
power source type: AC
power supply: 135 W
product colour: Anthracite, Black
products per master (outer) case: 9 pc(s)
quantity per pack: 1 pc(s)
thunderbolt 4 ports quantity: 2
thunderbolt ports quantity: 3
uasp support: Yes
usb 3.2 gen 2 (3.1 gen 2) type-a ports quantity: 4
usb power delivery (usb pd): Yes
usb power delivery revision: 3.0
usb power delivery up to: 96 W
usb type-c displayport alternate mode: Yes
weight: 435 g
width: 200 mm
windows operating systems supported: Yes
Description
| What is Thunderbolt™ 4? It is the superset standard that includesUSB4®, DisplayPort™ and PCI Express (PCIe). With Thunderbolt™ 4, a data transfer rate of up to 40 Gbit/s (at 2 m cable length) as well as 32 GB/s PCIe data transfer must be guaranteed, at least one 100 W charging port must be available and wake-up from sleep mode must be possible. What is the difference between Thunderbolt™ 3 and 4? Theoretically, a Thunderbolt™ 3 device should be able to do the same as a Thunderbolt™ 4 device. However, compared to version 3, Thunderbolt™ 4 now has to meet much stricter standards to be certified. This includes, among other things, support for two 4K displays or one 8K display. IB-DK8801-TB4 prevents cyber attacks This is realised through Virtualisation Technology for Directed I/O (VT-d). It prevents physical DMA attacks by protecting PCIe peripherals from unauthorised access to memory using DMA remapping. Access is thus only allowed to an isolated and allocated memory of a specific device. |
