Schroff RatiopacPRO AIR Radial Fan Unit, 1 Fan, 42 HP, 160 mm
To purchase this product you must be registered in our system.
Specification
depth: 160 mm
depth of packaging (single piece): 250 mm
gross weight: 0.337
height of packaging (single piece): 70 mm
manufacturer: SCHROFF
package weight (single piece): 0.337 kg
product group: SCHROFF 19" cabinets & expansion parts
product type: Ratiopac PRO
width: 218 mm
width of packaging (single piece): 120 mm
width units: 42 HP
Description
RatiopacPRO Air radial fan unit, 1 fan, 42 HP, 160 mmFAN UNIT 42HP 160D CPL. Only 1/2 U high - Centrifugal fans with ball bearings - Fan supports in 4 widths and 2 depths - Air flow rate 36 m3/h (free-blowing) per fan - Air discharge via perforation in the cover plate - No mechanical processing of the housing required - Simple installation - No restriction of the rear installation space |
