Intellinet 54-P PoE+ Managed Switch 6x10GbE 850W

Product Code: 562041

Barcode 0766623562041

To purchase this product you must be registered in our system.

Specification

Description

Related products

Specification

10g support: Yes

ac input frequency: 50/60 Hz

ac input voltage: 100 - 240 V

access control list (acl): Yes

arp inspection: Yes

auto mdi/mdi-x: Yes

auto-negotiation: Yes

auto-sensing: Yes

basic switching rj-45 ethernet ports quantity: 48

basic switching rj-45 ethernet ports type: Gigabit Ethernet (10/100/1000)

broadcast storm control: Yes

cable types supported: Cat5e

cables included: AC

certification: FCC, CE, RoHS, UKCA, NDAA

copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T

depth: 350 mm

dhcp features: DHCP client, DHCP relay, DHCP server, DHCP snooping

ethernet lan data rates: 10,100,1000 Mbit/s

flow control support: Yes

forwarding rate: 160.7 Mpps

full duplex: Yes

gigabit ethernet (copper) ports quantity: 48

half duplex: Yes

height: 44 mm

housing material: Metal

igmp snooping: Yes

ip routing: Yes

ipv4 fib entries: 24000

ipv6 fib entries: 6000

jumbo frames: 12000

jumbo frames support: Yes

led indicators: Activity, Link, PoE, Power

link aggregation: Yes

mac address auto-aging supported: Yes

mac address auto-learning supported: Yes

mac address table: 32000 entries

management protocols: SNMP

manual: Yes

master (outer) case gross weight: 20.7 kg

master (outer) case height: 465 mm

master (outer) case length: 550 mm

master (outer) case width: 355 mm

mean time between failures (mtbf): 90000 h

multicast support: Yes

networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

number of fans: 3 fan(s)

operating relative humidity (h-h): 5 - 95%

operating temperature (t-t): 0 - 40 °C

package depth: 425 mm

package height: 100 mm

package type: Box

package weight: 6.44 kg

package width: 505 mm

packet buffer memory: 16 MB

port mirroring: Yes

power connector: AC-in jack

power consumption (max): 900 W

power over ethernet (poe): Yes

power over ethernet (poe) power per port: 30 W

power over ethernet (poe) voltage: 52 V

power over ethernet plus (poe+) ports quantity: 48

power protection features: Over voltage, Overload, Short circuit, Surge protection

power source: AC

product colour: Black

products per master (outer) case: 3 pc(s)

quality of service (qos) support: Yes

rack mount kit: Yes

rack mounting: Yes

rate limiting: Yes

routing protocols: OSPF, RIP, VRRP

sfp+ module slots quantity: 6

storage relative humidity (h-h): 10 - 95%

storage temperature (t-t): -10 - 70 °C

store-and-forward: Yes

switch layer: L3

switch type: Managed

switching capacity: 216 Gbit/s

system event log: Yes

total power over ethernet (poe) budget: 850 W

virtual lan features: Port-based VLAN, Tagged VLAN

vlan support: Yes

warranty period: 3 year(s)

web-based management: Yes

weight: 5.5 kg

width: 440 mm

Description

Layer 3 switch with dynamic IP routing, a massive 850 W PoE power budget and six 10G Uplinks
L3 Switch for Next-Level Switching
The Intellinet Network Solutions 54-Port L3 Fully Managed PoE+ Switch with 48 Gigabit Ethernet Ports and 6 SFP+ Uplinks provides excellent network management and communication to fit your mix of devices, existing media and speed requirements. It features 48 x 10/100/1000 Mbps PoE+-capable ports, an available power budget of 850 W, six 10G/1G-capable SFP+ ports, a switching capacity of 216 Gbps, and a range of great Layer 2 and Layer 3 features. Its dynamic IP routing solution includes OSPF, RIP and VRRP, which makes it ideal for enterprise networks. It offers convenient configuration via a Web browser (among others) and is Domotz-compatible for easy cloud management.

Layer 2, Layer 2+, Layer 3 Lite and Layer 3 explained
This Layer 3 switch gives you the most feature-rich options, but what separates it from the other types? The main difference between Layer 2 and Layer 3 switches is the routing function. An L2 switch only operates on MAC addresses, not on IP addresses or anything on higher layers, while an L3 switch can do all that plus static and dynamic routing. Consequently, a Layer 3 switch has a MAC address table and an IP routing table, handling communication within a VLAN and between different VLANs. A compromise between both are L2+ switches (also known as Layer 3 Lite) that only support static routing. Besides routing packets, Layer 3 switches also have functions that require understanding the IP address information of the data entering the switch, such as assigning VLAN traffic based on IP address instead of manually configuring a port.

Power over Ethernet 802.3at
Supporting the IEEE 802.3at protocol, this switch is designed to inject up to 30 watts of power per port*. IEEE802.3af or IEEE802.3at compliant devices attached to the switch require no additional power, which eliminates the time and expense of electrical rewiring and minimizes the unsightly clutter of power supplies and adapters on ceilings and walls. Any mix of PoE and non-PoE devices is supported, and thanks to its short circuit, overload and high-voltage protection function, your equipment is well-protected. For devices that are not 802.3at/af compliant (legacy wireless access points or network cameras), we suggest the use of an Intellinet Network Solutions PoE/PoE+ Splitter.

10 Gigabit Ethernet (IEEE 802.3ae)
Equipped with six 10G SFP+ open slots, this switch is the ideal solution for cost-sensitive organizations considering 10 Gigabit Ethernet. With 10G technology going mainstream and becoming ever more popular, the need for additional bandwidth is more urgent than ever, even in smaller networks. Whether you wish to connect servers, network-attached-storage units or NVRs at 10 Gbps, or simply connect to another gigabit switch without using LACP techniques, 10G provides the solution. If you are not quite ready for 10G, this switch's SFP slots accept standard 1G SFP transceiver modules until the time is right for you to make the change.

Complete IPv6 Support
IPv6 management and SMB features like MLD Snooping, SSH, ACL, WRR and RADIUS authentication help you enter the IPv6 era at the lowest cost, without upgrading your hardware.

Self-Healing Network with increased reliability and stability - Intellinet Powered Device Monitor (PDM)
This Power over Ethernet switch is equipped with Powered Device Monitoring, a self-healing PoE function. This PoE watchdog performs a PD alive check on all connected PDs and automatically resets unresponsive devices, such as PoE security surveillance cameras, by cutting off and then restoring power. The PDM function is especially useful in applications where connected devices are critical to network operation, such as in industrial or surveillance settings. As an added benefit, the PD Alive function helps eliminate unnecessary technical support calls and costly field trips by field-support engineers because the functional reboot can often bring the unresponsive device back online.

How our PoE scheduling saves you energy
As part of our Self-Healing Networks suite, our managed switches are not only capable of providing high power but also of controlling the power supply efficiently. The "PoE scheduling" function allows you to turn on or off the PoE power for each PoE port at specific time intervals. Turning off devices like IP phones and access points outside of office hours helps your enterprise reduce its energy costs and protect the environment.
