Level One LevelOne NVR-0504 4-Kanal Netzwerk Videorek. PoE H.265/264
To purchase this product you must be registered in our system.
Specification
ac adapter included: Yes
audio rca inputs: 1
audio rca outputs: 1
browser supported: Internet Explorer 9+
cables included: AC
cd manual: Yes
certification: CE, FCC, ISO9001, ISO14001
compliance certificates: RoHS
country of origin: China
depth: 48 mm
ethernet lan (rj-45) ports: 4
hdd capacity: 0 GB
hdd size: 3.5"
hdmi output: Yes
hdmi ports quantity: 1
height: 315 mm
led indicators: HDD, Power
master (outer) case gross weight: 12.8 kg
master (outer) case height: 313 mm
master (outer) case length: 503 mm
master (outer) case width: 723 mm
maximum resolution: 3840 x 2160 pixels
maximum storage capacity: 6 TB
mobile operating systems supported: Android, iOS
networking standards: IEEE 802.3at
number of hdds supported: 1
number of users: 32 user(s)
on/off switch: Yes
operating relative humidity (h-h): 10 - 90%
operating system installed: Embedded LINUX
operating temperature (t-t): -10 - 55 °C
package depth: 290 mm
package height: 85 mm
package type: Box
package weight: 1.15 kg
package width: 485 mm
power consumption (typical): 65 W
power over ethernet (poe): Yes
power over ethernet (poe) ports quantity: 4
product colour: Black
products per master (outer) case: 8 pc(s)
supported network protocols: TCP,UDP,IPv4,IPv6,Http,Https,SMTP,NTP,SNTP
throughput data rate: 80 Mbit/s
usb 2.0 ports quantity: 2
vga (d-sub) output ports: 1
video formats supported: H.264, H.265, MPEG4
video input channels: 4 channels
weight: 1 kg
width: 240 mm
Description
| The LevelOne NVR-0504 NVR enables live view, recording and playback for up to 4 IP network cameras at the same time, featuring up to 8-megapixel resolution and H.265/H.264+/H.264 video compression. Operation is easy and intuitive via the web browser interface (IE), enabling remote monitoring and functionality. Mobile device operations are also supported (iOS/Android), with remote viewing via the LevelOne NVR app. The NVR also features built-in HDMI, VGA and USB ports for peripheral devices such as a monitor, mouse or keyboard, allowing users to operate directly from the NVR without the cost of adding a PC to the deployment. One HDD bay completes the package, with a disk capacity of up to 6TB making the LevelOne NVR-0504 a powerful, smart and cost-effective solution for managing your security network. An integrated 4-port 802.3at PoE switch enables the NVR to run both power and data on the one cable to power up connected PoE cameras. Central Management System (CMS) software is included for free, with no license fees. The CMS is capable of managing up to 256 NVRs, making it suitable for large scale surveillance applications. |
