| This antenna by Delock allows the usage of different 5G and LTE bands indoors and outdoors. System requirements: • Device with a free SMA connector Specification: • Connector: 1 x SMA plug • Frequency range: 698 MHz - 960 MHz 1710 MHz - 2170 MHz 2500 MHz - 2700 MHz 3400 MHz - 3800 MHz • 5G, ZigBee, LoRa, DECT, Z-Wave, NB-IoT, Bluetooth, GSM, UMTS, LTE, ISM, WLAN 2.4 GHz • Antenna gain: 0 - 3 dBi • Impedance: 50 Ohm • VSWR: 2.0 • Polarisation: linear, vertical • Operating temperature: -20 °C ~ 70 °C • Housing material: ABS • Colour: black • Protection class: IPX5 • Cable: coaxial • Cable type: RF195 • Cable colour: black • Cable attenuation: 0.46 dB @ 1.5 GHz per meter • Cable diameter: ca. 4.95 mm • Cable length incl. connector: ca. 3 m • Dimensions (LxD): ca. 110.0 x 77.0 mm Package content: • Antenna Data sheet: http://www.delock.de/produkt/12590/pdf.html?sprache=en |
