Draka Holding DRAKA UC300 S24 F/UTP H AWG 24 grau, 100 m Ring

DRAKA HOLDING

Draka Holding DRAKA UC300 S24 F/UTP H AWG 24 grau, 100 m Ring

Produkta kods: 1000056-00100RW
Svītrkods: 8717511213691

Lai varētu iegādāties šo produktu, jābūt reģistrētam mūsu sistēmā.

Specifikācija
Preces apraksts
Līdzīgas preces
Specifikācija
bend radius: min. 50 mm bei Zugbelastung
cable lsoh: ja
conductor cross section (awg): AWG 24
conductor type: Massivdraht
contents: 100 m
current catalog edition: 24.1
current catalog page: 1.50
depth of packaging (single piece): 300 mm
external cable diameter: 5,9 mm
fire protection class: Eca
garums: 100 m
gross weight: 3
height of packaging (single piece): 80 mm
impedance: 100 Ohm
manufacturer: Draka Holding
material (external cable mantle): FRNC
package weight (single piece): 3 kg
product group: Twisted Pair Kabel
product type: Installationskabel
quantity of wires: 8
shield type: F/UTP
technical particularity: Skew bei 100 MHz (Richtwert): 20 ns/100m
transfer quality: Cat5e / Class D
width of packaging (single piece): 300 mm
