The FME series is a miniature coax connector with screw coupling. The FME series can be used up to a frequency of 2 GHz. The impedance is controlled at 50 Ω. Connector styles are available for flexible and conformable cables. Solder and crimp techniques are used to terminate this series. Applications for the FME series are in the area of mobile communications, especially in vehicles due to their compact size and durability.

• Article name: Adapt str FMEm - SMAm (Old item number J01703A0009)
• Type: FME (m) / SMA (m)
• Max. Frequency: 2 GHz

• Contact resistance inner conductor ≤ 10 mΩ
• Contact resistance outer conductor ≤ 5 mΩ
• Insulation resistance ≥ 5 GΩ
• Voltage proof 1 kVeff/50 Hz
• Impedance 50 Ω
• Working voltage ≤ 100 Veff/50 Hz
• Insertion loss ≤ 0.2 dB/1.8 GHz
• Return loss ≥ 20 dB/1.8 GHz
• Frequency range up to 2 GHz

Remark: Picture similar
