Connectors

• Connector A: USB4 Type C Male
• Connector B: USB4 Type C Male
• Housing Material: PVC
• Shielding in head shell: -
• Connector Plating: Nickel
• Pin Construction: Copper
• Pin Plating: Gold
• Dimensions (approx.) WxDxH: 34.8x12.7x7.4mm (1.37x0.5x0.29in)

Cable Construction

• Jacket Diameter: 4.5mm (0.18in)
• Jacket Material: PVC
• Conductor Material: Copper
• Conductor Gauge Power: 24AWG
• Conductor Gauge Data: 32AWG
• Shielding: Aluminium Foil + 60% Braiding

Specifications

• Length: 2m (6.56ft)
• Colour: Black
• Type: Round
• Standard: USB4 Gen 3x2
• Supported Bandwidth: 40Gbps
• Maximum Power: PD 3.1 with EPR up to 240W (48V 5A)
• E-Mark: Yes
• Maximum Resolution: 3840x2160@60Hz, 7680x4320@60Hz
• Supported Procotols: USB4, USB 3.2, USB 2.0, Thunderbolt 3, DisplayPort 2.0
• Nominal Attenuation: -12. 2dB@5G, -18.3dB@10G
• Minimum Bend Radius: 20mm (0.79in)
• Operating Temperature: 0°C - 40°C (32°F - 104°F)
• Storage Temperature: -10°C - 60°C (14°F - 140°F)

Miscellaneous

• Packaging Type: Polybag
• Warranty (Years): 2
• Product Compliance: RoHS, REACH, California Proposition 65

Purchasing Information

• No.: 37002
• EAN: 4002888370028

This product is also available in other lengths

• 37000 - 0.5m (1.64ft)
• 37001 - 1m (3.28ft)
• 37002 - 2m (6.56ft)
