Specifications

• Input Voltage: 110-250V 50/60Hz 16A
• Switched Power (total): max. 2500W
• Voltage Range: 110-250V
• Nominal Input Frequency: 45-65Hz
• Current Range: 0A-16A
• No-load power consumption: 1.7W
• LED indicators

Functions

• Voltage, current and consumption monitoring
• Scheduler
• Email server
• Power-on and power-off delay
• Overcurrent and overvoltage protection
• Power-off memory
• Open APIs, web GUI & RS-232 control
• Support Telnet, Modbus TCP, SSH, SNMP and MQTT protocols

Connectors

• Input: IEC C20
• Output: 8x IEC C13
• Network Connection: 2xRJ-45 redundant Ethernet ports
• Sensor ports: 2xRJ-45
• Control: RS-232 3-pin phoenix

Physical Properties

• Dimensions (approx.) WxDxH: 436x225x44mm (17.17x8.86x1.73in)
• Housing Material: Metal
• Net Weight: 1.1kg (2.43lb)
• Operating Temperature: -5-55°C (23°F-131°F)
• Storage Temperature: -20-70°C (-4°F-158°F)
• Humidity: 0-80% (non-condensing)
• Colour: Black

Miscellaneous

• Packaging Type: Carton
• Packaging Dimensions: 540x422x87mm (21.26x16.61x3.43in)
• Gross Weight: 2.5kg (5.51lb)
• Warranty (Years): 3
• Certification: CE, UKCA, FCC, RoHS, REACH, EMC, LVD

Package Contents

• 8 Port IPower Switch
• Mounting kit with brackets
• RS232 3-pin to DB9 Female cable, 1.35m
• Schuko and UK to IEC C19 power cables, 1.8m
• 4x rubber feet
• Lindy Manual

Purchasing Information

• No.: 32623
• EAN: 4002888326230
