Specifications

• USB Standard: USB 2.0
• Protocol: Dante Ultimo, AES67
• Supported Bandwidth: 100Mbps
• Maximum Distance: 100m (328.08ft)

Connectors

• Input: USB Type C (Female)
• Output: RJ45 (Female)

Physical Properties

• Dimensions WxDxH: 114x48x26mm (4.48x1.88x1.02in)
• Housing Material: Metal
• Net Weight: 0.162kg (0.35lb)
• Operating Temperature: -5°C  - 55°C (23°F - 131°F)
• Storage Temperature: -25°C - 70°C (-13°F - 158°F)
• Power Requirements: 5VDC 1A / 802.3af PoE
• Power Consumption: 9W (max)
• Colour: Black

Miscellaneous

• Packaging Type: Carton Box
• Packaging Dimensions: 156x85x42mm (6.14x3.35x1.65in)
• Gross Weight: 0.215kg (0.47lb)
• Warranty (Years): 3
• Product Compliance: CE, UKCA, FCC, RoHS & REACH, CP65

Package Contents

• USB-C Dante In/Out Converter
• USB Type C/C Cable
• USB Type C/A Cable
• 2x mounting ears with screws
• User Manual

Purchasing Information

• No.: 70617
• EAN: 4002888706179
