Sākums Adapteri / Konverteri USB Lindy DST-Micro, USB-C Laptop Micro Docking Station with 4K Support & 100W Pass-Through Charging
Lindy DST-Micro, USB-C Laptop Micro Docking Station with 4K Support & 100W Pass-Through Charging

LINDY

Lindy DST-Micro, USB-C Laptop Micro Docking Station with 4K Support & 100W Pass-Through Charging

Produkta kods: 43336
Svītrkods: 4002888433365

Lai varētu iegādāties šo produktu, jābūt reģistrētam mūsu sistēmā.

Specifikācija
Preces apraksts
Līdzīgas preces
Specifikācija
ce doc: CE_DoC_DE_43336.pdf
ce docs: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/6d/55/97/62/6297556da7fecca6d5a65eb1/CE_DoC_DE_43336.pdf
compliance certificates: CE, REACH, RoHS
connectivity technology: Wired
country of origin: CN
depth: 38 mm
gross weight: 0.06
hdcp: Yes
hdcp version: 2.2
hdmi ports quantity: 1
height: 8.5 mm
host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-C
housing material: Aluminium
manual: Yes
manuals: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/7a/8b/69/66/66698b7a5c04c3fb5e40424c/LINDY_43336_MAN_0624.pdf,https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/ef/72/60/65/656072ef521eef9667192347/LINDY_43336_MAN_0322.pdf
maximum digital resolution: 3840 x 2160 pixels
net weight: 0.04
operating relative humidity (h-h): 5 - 90%
operating temperature (t-t): -20 - 40 °C
output current: 3 A
output voltage: 20 V
package depth: 194 mm
package weight: 60 g
package width: 174 mm
packaging height: 19.40
packaging lenght: 17.40
packaging width: 0.00
plug and play: Yes
power source type: USB
product colour: Black
quantity per pack: 1 pc(s)
storage relative humidity (h-h): 5 - 90%
storage temperature (t-t): -40 - 80 °C
tech data sheets: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/f2/67/97/62/629767f2d0ebe20d37a65ec1/43336_TDS_v1.pdf,https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/3f/46/6e/63/636e463f7841617ce6dc513e/43336_TDS_v2.pdf
usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity: 1
usb power delivery (usb pd): Yes
usb power delivery revision: 3.0
usb power delivery up to: 60 W
usb type-c displayport alternate mode: Yes
warranty: 2
weight: 42 g
width: 75 mm
Preces apraksts

Specifications

  • AV Interface: USB Type C to HDMI®
  • Supported Bandwidth: HDMI® 2.0 with 18Gbps
  • Maximum Input Resolution: 3840x2160@60Hz
  • Maximum Output Resolution: 3840x2160@60Hz
  • Chipset:  ANX7518
  • Compatibility: USB Type C/Thunderbolt equipped computers with DisplayPort Alternate Mode support. Windows, macOS, Linux, Android, ChromeOS.
  • Power Delivery: PD 3.0 up to 100W (20V 5A)
  • HDCP Support: HDCP 1.4/2.2/2.3
  • Supported Audio: -
  • Separate Audio Ports: -
  • Special Features: DisplayPort Alternate Mode

Connectors

  • Inputs: 1 x USB Type C (Male)
  • Outputs: 1 x HDMI® (Female), 1 x USB Type A (Female)
  • Power: Bus-powered

Physical Properties

  • Dimensions WxDxH: 75x38.5x8.5mm (2.95x1.52x0.33in)
  • (Fixed) Cable Length: -
  • Housing Material: Aluminium
  • Net Weight: 0.042kg (0.09lb)
  • Operating Temperature: -20°C - 40°C (-4°F - 104°F)
  • Storage Temperature: -40°C - 80°C (-40°F - 176°F)
  • Humidity: 5 - 90% RH (non-condensing)
  • Power Requirements: -
  • Colour: Black

Miscellaneous

  • Packaging Type: Polybag
  • Packaging Dimensions: 174x194mm (6.85x7.64in)
  • Gross Weight: 0.06kg (0.12lb
  • Warranty (Years): 2
  • Product Compliance: CE, FCC, REACH & RoHS, CP65

Package Contents

  • USB-C Laptop Micro Docking Station
  • Lindy Manual

Purchasing Information

  • No.: 43336
  • EAN: 4002888433365



CE Doc: CE_DoC_DE_43336.pdf
Tech Data Sheets: 43336_TDS_v2.pdf
Manuals: LINDY_43336_MAN_0322.pdf
