19" compatible: Yes, optional
analogue console: monitor connection: 1x HD 15pin F
analogue console: mouse/keyboard connection: 2x USB Type A
audio switching: Speakers and microphones
audio switching separately: no
cascadable: yes
colour: black
current catalog edition: 24.1
current catalog page: 3.12
depth: 160 mm
depth of packaging (single piece): 550 mm
dimensions (hxwxd): 44.5 x 450 x 170
gross weight: 2.626
height: 44 mm
height of packaging (single piece): 130 mm
hot plug compatible: no
integrated console: no
integrated hub: no
keyboard/mouse emulation: yes
mains connection: Appliance Europlug, Type-C
manufacturer: ATEN
material (casing): Metal
max. resolution (nominal): 2048x1536
package weight (single piece): 2.626 kg
pc: combi connection: 8x SPHD 15pin F
pc: connection on moulded cables: no
power supply output: 5V DC / 2.6A
power supply unit required: yes
print button on device: yes
product group: KVM switches / PC shares
product type: KVM-Switch, VGA
quantity of analogue consoles: 1
quantity of pcs: 8
scope of delivery: 1x CS1308 KVM Switch with Rack Mount Kit, 1x Console cabl...
supported pc-systems: PS/2 USB
switching over hot keys: Keyboard
switching over osd: yes
switching over scan run: yes
technical particularity: LED-Anzeige für Port-Status
weight: 1.89 kg
width: 430 mm
width of packaging (single piece): 240 mm
