Connectors

• Connector A: USB Type C Male
• Connector B: HDMI® Type A Male
• Housing Material: Type C: PVC, HDMI®: ABS
• Connector Plating: Gold plating
• Pin Construction: Phosphor Bronze
• Pin Plating: Gold plating
• Dimensions (approx.) WxDxH:
• A: 12.6x24x6.6mm (0.5x0.94x0.26in)
• B: 22x45.1x12mm (0.87x1.77x0.47in)

Cable construction

• Length: 1m (3.28ft)
• Standard: HDMI® 2.0 with 18Gbps
• Colour: Black
• Type: Round
• Jacket Diameter: 5.0mm (0.2in)
• Jacket Material: PVC
• Conductor Material: Tinned Copper
• Conductor Gauge: 32AWG
• Shielding: AL/MG Braid 85%

Specifications

• Chipset: ITE6563
• Supported Bandwidth: 18Gbps
• Power Delivery: -
• Maximum Resolution: 4096x2160@60Hz 4:4:4 8bit / 4:2:2 12bit
• Nominal Attenuation: 0.1MHz-6MHz<12DB
• Minimum Bend Radius: 47mm (1.85in)
• Operating Temperature: 0°C - 35°C (32°F - 95°F)
• Storage Temperature: 0°C - 45°C (32°F - 113°F)

Miscellaneous

• Packaging Type: Polybag
• Warranty (Years): 2
• Product Compliance: CE, FCC, RoHS, REACH & UL

Purchasing Information

• No.: 43291
• EAN: 4002888432917

This product is also available in other lengths:

• 43291 - 1m (3.28ft)
• 43292 - 2m (6.56ft)
• 43293 - 3m (9.84ft)
