ATEN

Aten CL3116NX KVM-Switch, 18,5" TFT, VGA, PS/2-USB, 16 Port, FR-Layout

Produkta kods: CL3116NX F
Svītrkods: 4710469343735

Lai varētu iegādāties šo produktu, jābūt reģistrētam mūsu sistēmā.

Specifikācija
19" shelves required for mounting: 2
colour: black
current catalog edition: 24.1
depth: 63.1 cm
depth of packaging (single piece): 720 mm
gross weight: 13.9
height: 4.28 cm
height of packaging (single piece): 140 mm
keyboard layout: FR
manufacturer: ATEN
monitor size of integrated console: 18.5" (47 cm)
package weight (single piece): 13.9 kg
product group: 19"-/10"-Equipment rack
product type: KVM-Switch, VGA
required mounting height: 1 U
scope of delivery: 1x CL3116 LCD KVM Switch with Standard Rack Mounting Kit,...
weight: 10.6 kg
width: 48.06 cm
width of packaging (single piece): 680 mm

Preces apraksts

The ATEN CL3116 LCD KVM Switch offers a space-saving, streamlined approach to KVM switch technology by integrating a keyboard, 18.5" LED-backlit LCD monitor, and a touchpad in a 1U rack-mountable sliding housing. The short-depth design maximizes space utility for equipping rack-mounting devices in narrow spaces. In addition, its exclusive LED illumination light provides users with proper visibility when working in low-light conditions.

The CL3116 can control up to 16 computers; when 16 additional KVM switches are cascaded, a single CL3116 LCD KVM Switch can control up to 256 computers. To achieve greater operational efficiency, the CL3116 offers Broadcast mode, which the console spreads out the commands to all computers to perform operations simultaneously. Besides, the Auto scan mode fulfills the needs for continuous monitoring a specific group of computers, and establishing a reliable working environment for users.

  • Keyboard Layout French
  • Exclusive LED illumination light – designed by ATEN to illuminate the keyboard and touchpad to allow visibility in low-light conditions
  • Integrated LCD KVM console with an 18.5'' LED-backlit widescreen LCD monitor in a single rail housing with top and bottom clearance for smooth operation in a 1U high system rack
  • Short-depth design allows you to work with your rack-mounting equipment in narrow spaces
  • Console lock – enables the console drawer to remain securely locked away in position when not in use
  • Superior video quality - up to 1366 x 768 @60Hz; DDC2B
  • Cascade up to 2 levels – CL3116 controls up to 256 computers from a single console (With compatible KVM Switches: CS1308/CS1316)
  • Dual Interface – supports computers with PS/2 or USB keyboards and mice
  • Auto PS/2 and USB interface detection
  • Keyboard and mouse emulation (PS/2 and USB) for smooth switching and simultaneously booting multiple computers even when the console focus is elsewhere
  • Computer selection via pushbuttons, hotkeys, and multilingual on-screen display (OSD)
