Level One LevelOne Konverter FVS-3800 10/100TX>100 X SFP

LEVEL ONE

FVS-3800

New

The LevelOne Web Smart Media Converter FVS-3800 is designed to make conversion between 10/100BASE-TX and 100BASE-X SFP Ethernet.With web-based management, the network administrator can logon to the converter remotely to monitor, configure and control the status of each unit. The overall network reliability is enhanced, and the network efficiency is also improved to accommodate and deliver high bandwidth applications.- HTTP Management with remote firmware upgrade supported - ICMP and ARP protocols supported - DHCP Client for easy IP address setup - LLR (Link Loss Return) supported - IEEE 802.1Q VLAN and Double VLAN (Q-in-Q) supported - Support 802.3x Flow Control to prevent lost data by controlling the device flow loading

Maximum data transfer rate100 Mbit/s
Converter input interface10Base-T, 100Base-TX
Networking standardsIEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet interface typeFast Ethernet
Ethernet LAN data rates10,100 Mbit/s
Jumbo frames supportY
Flow control supportY
Fiber optic connectorSFP
Connectivity technologyWired
Ethernet LAN (RJ-45) ports1
Fiber ports quantity1
DC-in jackY
InternalN
LED indicatorsY
Product colourGrey
Country of originTaiwan
CertificationFCC Part 15 Class A, CE
Input voltage5 V
Input current1 A
Power consumption (typical)1.5 W
External power adapterY
Width70.3 mm
Depth26.2 mm
Height94 mm
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 90%
Package width160 mm
Package depth220 mm
Package height60 mm
Package weight470 g
ManualY
Harmonized System (HS) code85176990
