LINDY 12m DisplayPort 1.4 Repeater

Lindy

38415

New

Extends DisplayPort 1.4 UHD signals over distances up to 35m Supports resolutions up to 7680x4320@60Hz 4:2:0 8bit and HDR Five level cascade functionality allows the extension of 8K UHD content up to 32m Compact form factor for discreet installation in presentation, conference and education spaces 2-year warrantyThe Lindy DisplayPort 1.4 Repeater is an active solution for amplifying and extending high-resolution 8K UHD DisplayPort signals up to distances of 12m, or up to five repeaters can be cascaded together to extend 8K signals up to 32m. 4K UHD and Full HD resolutions can also be extended at distances up to 35m using a single repeater.Support for 8K UHD resolutions and HDR are combined to create an exceptional viewing experience with enhanced brightness, greater contrasts and a much wider colour gamut. HDMI and multi-channel audio formats such as Dolby Atmos, Dolby TrueHD & DTS-X help to create a true sense of immersion when coupled with UHD resolutions and high refresh rates up to 144Hz in PC gaming and other applications. HDCP and DPCP 1.0 support ensures maximum compatibility with copy protected digital content from streaming services or media players.By amplifying an input signal, the repeater overcomes the limitations of passive copper cables and can extend DisplayPort signals without errors over greater distances than traditional cables.The repeater’s small form factor allows it to be easily hidden for discreet installations and its versatility ensures it can seamlessly integrate into many applications. Support for various resolutions, refresh rates and transmission distances make this repeater perfect for CAD, PC gaming, video & photo editing applications, or in collaborative environments such as presentation, conference and education spaces.

TypeAV repeater
Maximum resolution7680 x 4320 pixels
Maximum transfer distance35 m
Maximum refresh rate60 Hz
Bandwidth32.4 Gbit/s
HDCPY
MaterialPlastic
Product colourBlack
CertificationCE, FCC, REACH & California Proposition 65
Connectivity technologyWired
DisplayPorts in1
DisplayPorts out1
DC-in jackY
Operating voltage5 V
Input current1 A
Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Width54 mm
Depth54 mm
Height19 mm
Weight32 g
Package width55 mm
Package depth100 mm
Package height140 mm
Package weight168 g
AC adapter includedY
ManualY
Sustainability certificatesRoHS

Converters / Transceivers / Repeaters
