ROLINE Field Plug Cat.6A (Class EA), STP, silver
Previous Next

ROLINE Field Plug Cat.6A (Class EA), STP, silver

ROLINE

21.17.0325

New

  • Fast and easy tool-free installable unshielded RJ45 connector
  • Cat.6A / Class EA performance according to ISO/IEC11801 and IEC60603-7
  • Compact cable manager for round AWG22/1-26/1(1/0.65-1/0.4mm) and stranded cable AWG 22/7-26/7 For cable OD:5.0-8.5mm
  • For cable with outer diameter OD: 5.0 - 8.5mm
  • Pair management according to TIA 568B and TIA 568A colour codes
  • Robust zinc die-cast housing
  • Strain relief with cable tie and black transparent dust cup and boot
  • Color: silver



ManufacturerROLINE
Product groupConnection technology TP
Product typeConnectors RJ-45
Coloursilver
Shield typeScreened
Transfer qualityCat6A / Class EA
Shield contactsja
separate strain reliefJā
Height13.4 mm
Width14.15 mm
Depth56.3 mm
Weight14.8 g
Current catalog editionC23-New.04
