APC USV SMX2200HV SMARTUPS X 2200VA Rack/Tower LCD 200-240V (Speditionsversand)

APC

SMX2200HV

New

Smart-UPS,1980 Watts /2200 VA,Input 230V, 230V /Output 230V, Interface Port SmartSlot, USB, Extended runtime model, Rack Height 4 UIncludes: CD with software, Rack Mounting brackets, Smart UPS signalling RS-232 cable, USB cable, User Manual

UPS topologyLine-Interactive
Output power capacity2.2 kVA
Output power1980 W
WaveformSine
Input operation voltage (min)140 V
Input operation voltage (max)280 V
Input frequency50/60 Hz
Output operation voltage (min)208 V
Output operation voltage (max)240 V
Output frequency regulation50/60 Hz
Automatic Voltage Regulation (AVR)Y
Surge energy rating645 J
Hold time (min)2 ms
Hold time (max)10 ms
Efficiency98.1%
Emergency Power Off (EPO)Y
Noise level55 dB
Surge protectionY
Audible alarm(s)Y
Auto-restartY
AC outlet typesC13 coupler, C19 coupler
Power plugC20 coupler
AC outlets quantity10 AC outlet(s)
Number of output IEC jumpers2
USB portY
SmartSlotY
Battery technologySealed Lead Acid (VRLA)
Battery capacity702 VAh
Typical backup time at full load9.8 min
Typical backup time at half load25.3 min
Battery life (max)5 year(s)
Battery recharge time3 h
Hot-swap batteryY
Automatic battery testY
Cold startY
Form factorRackmount/Tower
Product colourBlack, Stainless steel
Rack capacity4U
Cable length2 m
Display typeLCD
LED indicatorsStatus, Battery replacement
CertificationCE, CSA, EAC, EN 50091-1, EN 50091-2, EN/IEC 62040-1, EN/IEC 62040-2, FCC Part 15 CL A, IEC 60950, IRAM, RCM, UL 1778, VDE, WEEE, REACH
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m
Sustainability certificatesRoHS
Width178 mm
Depth483 mm
Height432 mm
Weight38.6 kg
Package width586 mm
Package depth633 mm
Package height330 mm
Package weight47.7 kg
Rack mount kitY
Cables includedRS-232, USB cable
Temperature sensorY
ManualY
Quick installation guideY
Software CDY
Products per pallet6 pc(s)
Harmonized System (HS) code85078000
Packaging contentWeb/SNMP Management Card

UPS lineinteractive
