Equip Adapter USB-C -> DisplayPort 1.4 8K60Hz 0.15m gr

EQUIP

133493

New

The equip® USB-C to DisplayPort 1.4 adapter is a device that allows you to connect a USB-C device, such as a laptop or smartphone, to a display that supports DisplayPort 1.4. This adapter supports high resolution and refresh rates, with a maximum resolution of 8K/30Hz.The adapter can transmit both video and audio signals, and supports HDCP 2.2 content protection. It is a convenient solution for users who want to connect their USB-C devices to a DisplayPort monitor or TV, and is especially useful for tasks that require high resolution and fast refresh rates, such as gaming, video editing, and graphic design.By supporting a maximum bandwidth of 32.4 Gbps, content up to 8K Ultra HD (7680 x 4320/30Hz) resolution can be displayed.

Cable length0.15 m
Connector 1USB Type-C
Connector 2DisplayPort
Connector 1 genderMale
Connector 2 genderFemale
Connector 1 form factorStraight
Connector 2 form factorStraight
Connector contacts platingGold
Power sourceUSB
HDCPY
HDCP version2.2
DisplayPort version1.4
Maximum resolution7680 x 4320 pixels
Supported graphics resolutions1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160, 5120 x 2880, 7680 x 4320
Data transfer rate32.4 Gbit/s
Maximum refresh rate240 Hz
Refresh rate at maximum resolution30 Hz
Product colourBlack, Grey
Cable typeRound cable
Plug and PlayY
Country of originChina
Sustainability certificatesRoHS, CE
Weight30 g
Width10 mm
Depth200 mm
Height20 mm
Quantity per pack1 pc(s)
Package width23 mm
Package depth75 mm
Package height148 mm
Package typeBox
Package weight560 g

USB
