D-Link DWL-6610AP W-LAN AC AccessP. PoE Dualb. o.N. 867Mbps retail

Manufacturer: D-LINK

Reference DWL-6610AP

Condition: New

More info

Next Generation Connectivity

Harness the power of Wireless AC and take advantage of combined wireless speeds of up to 1200 Mbps,
perfect for high demand business applications

Enhanced Level of Performance

Experience faster and stable performance as well greater coverage with beamforming, and better
managed traffic with band steering

Unparalleled Flexibility and Scalability

Used as a standalone wireless access point, self-configuring cluster or managed centrally via a D-Link
Wireless Controller or Unified Switch

2.4 GHz	Jā
5 GHz	Jā
Maximum data transfer rate	1200 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
VLAN support	Jā
Quality of Service (QoS) support	Jā
Security algorithms	AES, HTTPS, SSH, TKIP, WPA, WPA2
MAC address filtering	Jā
Management protocols	SNMP
Web-based management	Jā
Ethernet LAN (RJ-45) ports	1
DC-in jack	Jā
Power over Ethernet (PoE)	Jā
Output voltage	12 V
Output current	2 A
Power consumption (max)	16.6 W
Housing material	Plastic
On/off switch	Jā
Reset button	Jā
Certification	CE EN 301 893 V1.7.1 (2012-06) (DFS/TPC) EN 300 328 V1.8.1 (2012-06) FCC IC cUL LVD UL2043 C-Tick BSMI NCC
Antenna gain level (max)	6.5 dBi
Shipping (inner) case length	56.5 cm
Shipping (inner) case width	34.3 cm
Shipping (inner) case height	27.5 cm
Shipping (inner) case net weight	6.39 kg
Products per shipping (inner) case	6 pc(s)
Pallet gross weight (air)	200.6 kg
Master (outer) cases per pallet (air)	24 pc(s)
Products per pallet (air)	144 pc(s)
Pallet gross length	110 cm
Pallet gross width	120 cm
Pallet height (air)	123.5 cm
Pallet gross weight (sea)	332.5 kg
Master (outer) cases per pallet (sea)	42 pc(s)
Products per pallet (sea)	252 pc(s)
Pallet height (sea)	2.06 m
Shipping (inner) case gross weight	7.3 kg
Width	158.8 mm
Depth	158.8 mm
Height	69.4 mm
Weight	500 g
Package width	243 mm
Package depth	235 mm
Package height	90 mm
Package weight	1.06 kg
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 65 °C
Harmonized System (HS) code	85176990
