Lindy 9 Port HDMI 4K30 Multi-View Switch

Lindy

LIN38330

Jauns

Specifications

  • AV Interface: HDMI
  • Interface Standard: HDMI 1.4
  • Supports Bandwidth: 10.2Gbps
  • Maximum Resolution: 3840x2160@30Hz 4:4:4 8bit
  • HDCP Support: 1.4
  • Supported Audio: HDMI Audio Pass-through
  • Separate Audio Ports: -
  • IR Support : 38KHz
  • CEC Support: -
  • Serial Interface: RS-232
  • Special Features: Seamless Switching



Connectors

  • Input: 9 x HDMI Type A (Female)
  • Output: HDMI Type A (Female)
  • Control: RS-232 Terminal Blocks (Female)
  • Power : 5.5/2.1mm



Physical Properties

  • Dimensions (approx.) WxDxH: 252x25x105mm (9.92x0.98x4.13in)
  • Housing Material: Metal
  • Net Weight: 0.792kg (1.75lb)
  • Operating Temperature: -15°C - 55°C (5°F - 131°F)
  • Storage Temperature: -15°C - 55°C (5°F - 131°F)
  • Humidity: 0 - 90% RH (non-condensing)
  • Power Requirements: 12VDC 2A
  • Colour: Black



Miscellaneous

  • Packaging Type: Carton Box
  • Packaging Dimensions: 577x40x511mm (22.72x1.57x20.12in)
  • Gross Weight: 1.3kg (2.87lb)
  • Warranty (Years): 2
  • Certificated: CE, FCC, RoHS, REACH & California Proposition 65



Package Contents

  • 9 Port HDMI 10.2G Multi-view Switch
  • Multi-country Power Supply (UK, EU, US & AUS)
  • 4 x Screws
  • IR Remote Control with CR2025 Battery
  • Lindy Manual



Purchasing Information

  • No.: 38330
  • EAN: 4002888383301
