LINDY DVI EDID Emulator

Lindy

32122

Jauns

Continuously emulates DVI EDID information Supports resolutions up to 2560x1600@60Hz For use with 32120 for cloning Powered via DVI Source Interface 2 Year warrantyThe Lindy DVI EDID Emulator is designed for systems that require EDID signals to be continuously provided without interruption and helps overcome EDID related problems which can occur when using AV/KVM extenders, switches and splitters. It can also be used in place of a monitor to keep the graphics card of a PC or server awake for remote access via IP. With support for resolutions up to 2560x1600@60Hz, the emulator is suitable for use with legacy PCs and displays. When used with the Lindy EDID recorder (32120) this device can provide cloned EDID information to the graphics card.It is also possible to use the Emulator without cloning a display as it comes complete with pre-set EDID data for the most commonly used resolution/timing combinations, please see the Technical Information section for a full breakdown.

Maximum video resolution2560 x 1600 pixels
Video resolutions720 x 400,640 x 480,800 x 600,1024 x 768,1280 x 1024,1280 x 720,1280 x 960,1600 x 1200,1680 x 1050,1920 x 1080,1920 x 1200,2560 x 1440,2560 x 1600
Bandwidth9.9 Gbit/s
Product colourBlack, Metallic
Housing materialMetal
Certification: CE, FCC, RoHS, REACH & California Proposition 65
Video port typeDVI-D
Number of video inputs1
Number of video outputs1
Width39 mm
Depth54 mm
Height14 mm
Weight35 g
Package width133 mm
Package depth144 mm
Package weight51 g
